ILSCO 2SC-125 CU MEC 2/0-1/0 B UL
Product image thumbnail 0
Product image thumbnail 1
$61.59/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # 2SC-125
North Coast Part # 1347330

Specifications

  • UPC Code: 78366997195
  • UNSPSC Code: 39121408
  • Dual Rated: FALSE
  • Conductor Range CU Stranded (Primary, run, main, line): 2/0 Str - 1/0 Str
  • Conductor Size CU (Primary, run, main, line): 2/0 Str,1/0 Str
  • Conductor Range CU Stranded (Secondary, tap, load): 2/0 Str - 1/0 Str
  • Conductor Size CU (Secondary, tap, load): 2/0 Str,1/0 Str
  • Drive Type Main: Slotted
  • Number of Wire Binding Screws per Port: 1
  • Wire Binding Screw Size: 16-Jul
  • Wire Binding Torque: 10 - 14 AWG = 35,8 AWG = 40,4 - 6 AWG = 45,2 AWG = 50
  • Length (IN): 1.266
  • Length (mm): 32.1564
  • Width (IN): 0.611
  • Width (mm): 15.5194
  • Height (IN): 0.906
  • Height (mm): 23.0124
  • Weight (LB): 0.134
  • Material: Copper
  • Conductor Material: Copper
  • Wire Binding Hardware Material: Steel
  • Wire Binding Hardware Finish: Zinc Clear Trivalent Chromate
  • Color: Copper
  • Direct Burial: FALSE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Connection: Mechanical
  • Conductor Type: Stranded
  • Contains DE-OX: FALSE
  • Number of Conductors: 2
  • Number of Poles: 1
  • Number of Ports / Wireways: 2
  • Number of Ports Main: 1
  • Number of Ports Tap: 1
  • Wire Orientation: Parallel
  • Bag Quantity: 1
  • CrossSell: DE-OX-8OZ

Overview

UPC 78366997195
GTiN 00783669971958
Type 2SC:SPLICER REDUCER
Material Copper
Applications Splicer/Reducer
Family Brand Name ILSCO
Sub Brand ILSCO
Finish NA
Color Copper
Number of Conductors 2
Temperature Rating 90 C
Number of Ports 1
TC Connection Mechanical
Voltage 35,000 Volt
