ILSCO ALNS-8-10 AL COMP 8 AWG 7/32
$9.08/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # ALNS-8-10
North Coast Part # 1343870

Specifications

  • UPC Code: 78366969043
  • UNSPSC Code: 39121448
  • Dual Rated: TRUE
  • Conductor Range CU Stranded (Primary, run, main, line): 8 Str
  • Conductor Size CU (Primary, run, main, line): 8 Str
  • Conductor Range AL Stranded (Primary, run, main, line): 8 Str
  • Conductor Size AL (Primary, run, main, line): 8 Str
  • Length (IN): 1.47
  • Length (mm): 37.338
  • Width (IN): 0.425
  • Width (mm): 10.795
  • Height (IN): 0.33
  • Height (mm): 8.382
  • Weight (LB): 0.006
  • Barrel Length (IN): 0.602
  • Barrel Length (mm): 15.2908
  • Dimension G (IN): 0.259
  • Dimension G (mm): 6.5786
  • Inside Diameter (IN): 0.155
  • Inside Diameter (mm): 3.937
  • Mounting Bolt/Stud Size (mm): 254
  • Mounting Hole Diameter (IN): 0.219
  • Mounting Hole Diameter (mm): 5.5626
  • Mounting Hole Spacing (mm): 0
  • Outside Diameter (IN): 0.3
  • Outside Diameter (mm): 7.62
  • Strip Length (mm): 16.8783
  • Tang Length (IN): 0.6
  • Tang Length (mm): 15.24
  • Tang Thickness (IN): 0.125
  • Tang Thickness (mm): 3.175
  • Tang Width (IN): 0.425
  • Tang Width (mm): 10.795
  • Material: Aluminum
  • Conductor Material: Copper,Aluminum
  • Connector Finish: Tin
  • Color: Silver
  • Die Color Code: Blue
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • UL Control Number: 453G
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Barrel Marking: Hard
  • Barrel Type: Long
  • Connection: Compression
  • Connecting angle: 180°
  • Conductor Type: Stranded
  • Contains DE-OX: TRUE
  • ILSCOs Die Catalog Number: ILD-374
  • Flared End: FALSE
  • ILSCOs Die Index Number: 374
  • Mounting Hole Type: Thru
  • Narrow Tang: FALSE
  • Number of Mounting Holes: 1
  • Sight Window: FALSE
  • Slotted: FALSE
  • Tang End Shape: Square
  • Undrilled: FALSE
  • Bag Quantity: 1
  • CrossSell: ILD-374, TB-6DF1000-P

Overview

UPC 78366969043
GTiN 00783669690439
Type ALNS:1 HOLE LONG BARREL
Material Aluminum
Applications Aluminum Compression Lug
Family Brand Name ILSCO
Sub Brand Surecrimp
Size L:1.47;W:0.425;H:0.33 IN
Color Silver
Temperature Rating 90 C
Conductor Type Stranded
