ILSCO CSWD-600-12-134 CU CMP 600 k
$49.98/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # CSWD-600-12-134
North Coast Part # 606815

Specifications

  • UPC Code: 78366964717
  • UNSPSC Code: 39121448
  • Dual Rated: FALSE
  • Conductor Range CU Stranded (Primary, run, main, line): 600 kcmil
  • Conductor Size CU (Primary, run, main, line): 600 kcmil
  • Flex Conductor Range: 400 G,H,I,K,M 444.4 DLO
  • Flex Conductor Size (Class G): 400 G
  • Flex Conductor Size (Class H): 400 H
  • Flex Conductor Size (Class I): 400 I
  • Flex Conductor Size (Class K): 400 K
  • Flex Conductor Size (Class M): 400 M
  • Flex Conductor Size (Class DLO): 444.4 DLO
  • Expanded Conductor Range: 600 kcmil - 250 kcmil
  • Expanded Conductor Size: 600 kcmil,550 kcmil,500 kcmil,450 kcmil,400 kcmil,350 kcmil,300 kcmil,250 kcmil
  • Mounting Bolt/Stud Size: 1/2/2020
  • Length (IN): 5.184
  • Length (mm): 131.6736
  • Width (IN): 1.712
  • Width (mm): 43.4848
  • Height (IN): 1.233
  • Height (mm): 31.3182
  • Weight (LB): 0.68802078
  • Barrel Length (IN): 1.375
  • Barrel Length (mm): 34.925
  • Dimension G (IN): 0.546
  • Dimension G (mm): 13.8684
  • Inside Diameter (IN): 0.92
  • Inside Diameter (mm): 23.368
  • Mounting Bolt/Stud Size (mm): 304.8
  • Mounting Hole Diameter (IN): 0.562
  • Mounting Hole Diameter (mm): 14.2748
  • Mounting Hole Spacing (IN): 1.75
  • Mounting Hole Spacing (mm): 44.45
  • Outside Diameter (IN): 1.188
  • Outside Diameter (mm): 30.1752
  • Strip Length (mm): 36.4998
  • Tang Length (IN): 3
  • Tang Length (mm): 76.2
  • Tang Thickness (IN): 0.267
  • Tang Thickness (mm): 6.7818
  • Tang Width (IN): 1.712
  • Tang Width (mm): 43.4848
  • Material: Copper
  • Conductor Material: Copper
  • Connector Finish: Tin
  • Color: Silver
  • Die Color Code: Green
  • Direct Burial: FALSE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • UL Control Number: 453G
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • NEBS Rating: Level 3
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Barrel Marking: Ink
  • Barrel Type: Standard
  • Connection: Compression
  • Connecting angle: 180°
  • Conductor Type: Stranded,Flex
  • Contains DE-OX: FALSE
  • ILSCOs Die Catalog Number: ILD-94
  • Flared End: FALSE
  • Mounting Hole Type: Thru
  • Narrow Tang: FALSE
  • Number of Mounting Holes: 2
  • Sight Window: TRUE
  • Slotted: FALSE
  • Tang End Shape: Square
  • Undrilled: FALSE
  • Bag Quantity: 1
  • CrossSell: ILD-94, DE-OX-8OZ, TB-6DF1000-P

Overview

UPC 78366964717
GTiN 00783669647174
Type CSWD:2 HOLE SHORT W/SIGHT
Material Copper
Applications Copper Compression Lug
Bolt Size 1/2 IN
Temperature Rating 90 C
Family Brand Name ILSCO
Sub Brand Surecrimp
Size L:5.184;W:1.712;H:1.233 IN
Color Silver
