ILSCO CT-600 UL Listed 600 MCM Copper Compression Sleeve
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$55.64/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # CT-600
North Coast Part # 340195

Specifications

  • UPC Code: 78366912550
  • UNSPSC Code: 39121449
  • Dual Rated: FALSE
  • Conductor Range CU Stranded (Primary, run, main, line): 600 kcmil
  • Conductor Size CU (Primary, run, main, line): 600 kcmil
  • Flex Conductor Range: 400 G,H,I,K,M 444.4 DLO
  • Flex Conductor Size (Class G): 400 G
  • Flex Conductor Size (Class H): 400 H
  • Flex Conductor Size (Class I): 400 I
  • Flex Conductor Size (Class K): 400 K
  • Flex Conductor Size (Class M): 400 M
  • Flex Conductor Size (Class DLO): 444.4 DLO
  • Expanded Conductor Range: 600 kcmil - 250 kcmil
  • Expanded Conductor Size: 600 kcmil,550 kcmil,500 kcmil,450 kcmil,400 kcmil,350 kcmil,300 kcmil,250 kcmil
  • Length (IN): 2.875
  • Length (mm): 73.025
  • Width (IN): 1.187
  • Width (mm): 30.1498
  • Height (IN): 1.187
  • Height (mm): 30.1498
  • Weight (LB): 0.464
  • Inside Diameter (IN): 0.92
  • Inside Diameter (mm): 23.368
  • Outside Diameter (IN): 1.187
  • Outside Diameter (mm): 30.1498
  • Material: Copper
  • Conductor Material: Copper
  • Connector Finish: Tin
  • Color: Silver
  • Die Color Code: Green
  • Direct Burial: FALSE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • UL Control Number: 453G
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • NEBS Rating: Level 3
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Barrel Marking: Ink
  • Barrel Type: Standard
  • Connection: Compression
  • Connecting angle: 180°
  • Conductor Type: Stranded,Flex
  • Contains DE-OX: FALSE
  • ILSCOs Die Catalog Number: ILD-94
  • Flared End: FALSE
  • Number of Conductors: 1
  • Number of Mounting Holes: 0
  • Sight Window: FALSE
  • Slotted: FALSE
  • Bag Quantity: 1
  • CrossSell: ILD-94, DE-OX-8OZ, TB-6DF1000-P

Overview

GTiN 00783669125504
Length 2-7/8 Inch
Voltage 600 Volt
Type Short Barrel
Material Copper
Conductor Size 600 kcmil
Applications Copper Compression Sleeve, Short Barrel
Standard NEBS Rating: LEVEL 3,UL File Number: E6207,CSA File Number: LR-29601,UL Specifications: UL 486A-B
Temperature Rating 90 C
Family Brand Name ILSCO
Outside Diameter 1.187 in
Inside Diameter 0.920 in
Color Coding Green
Sub Brand SureCrimp
Product UPC 78366912550
Finish Tin Plated
Size L:2.875;W:1.187;H:1.187 IN
Color Silver
TC Connection Compression
Blade Dimensions 1-3/16 in W x 1-3/16 in H
