ILSCO CTL-250 UL CSA Listed 250 MCM Copper Compression Sleeve
Product image thumbnail 0
Product image thumbnail 1
$31.29/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # CTL-250
North Coast Part # 268377

Specifications

  • UPC Code: 78366912835
  • UNSPSC Code: 39121449
  • Dual Rated: FALSE
  • Conductor Range CU Stranded (Primary, run, main, line): 250 kcmil
  • Conductor Size CU (Primary, run, main, line): 250 kcmil
  • Flex Conductor Range: 4/0 G,H,I,K,M,DLO
  • Flex Conductor Size (Class G): 4/0 G
  • Flex Conductor Size (Class H): 4/0 H
  • Flex Conductor Size (Class I): 4/0 I
  • Flex Conductor Size (Class K): 4/0 K
  • Flex Conductor Size (Class M): 4/0 M
  • Flex Conductor Size (Class DLO): 4/0 DLO
  • Expanded Conductor Range: 250 kcmil - 1/0 Str
  • Expanded Conductor Size: 250 kcmil,4/0 Str,3/0 Str,2/0 Str,1/0 Str
  • Length (IN): 3.375
  • Length (mm): 85.725
  • Width (IN): 0.75
  • Width (mm): 19.05
  • Height (IN): 0.75
  • Height (mm): 19.05
  • Weight (LB): 0.233
  • Inside Diameter (IN): 0.594
  • Inside Diameter (mm): 15.0876
  • Outside Diameter (IN): 0.75
  • Outside Diameter (mm): 19.05
  • Material: Copper
  • Conductor Material: Copper
  • Connector Finish: Tin
  • Color: Silver
  • Die Color Code: Yellow
  • Direct Burial: TRUE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • UL Control Number: 453G
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed,UL 467 Listed
  • NEBS Rating: Level 3
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Barrel Marking: Ink
  • Barrel Type: Long
  • Connection: Compression
  • Connecting angle: 180°
  • Conductor Type: Stranded,Flex
  • Contains DE-OX: FALSE
  • ILSCOs Die Catalog Number: ILD-62
  • Flared End: FALSE
  • Number of Conductors: 1
  • Number of Mounting Holes: 0
  • Sight Window: FALSE
  • Slotted: FALSE
  • Bag Quantity: 1
  • CrossSell: ILD-62, DE-OX-8OZ, TB-6DF1000-P

Overview

UPC 78366912835
GTiN 00783669128352
Length 3-3/8 in
Voltage 600 Volt
Type Long Chamfered Barrel
Material Copper
Conductor Size 250 kcmil Stranded/Solid
Applications Copper Compression Sleeve, Long Barrel
Standard UL Specifications: UL 486A-B,NEBS Rating: LEVEL 3,UL File Number: E6207,CSA File Number: LR-29601
Temperature Rating 90 C
Family Brand Name ILSCO
Outside Diameter 0.750 in
Inside Diameter 0.593 in
Color Coding Yellow
Sub Brand SureCrimp
Finish Electro Tin Plated
Size L:3.375;W:0.75;H:0.75 IN
Color Silver
Connector Type Compression
Conductor Type Aluminum/Copper
TC Connection Compression
Blade Dimensions 3/4 in W x 3/4 in H
