ILSCO CTL-750 UL CSA Listed 750 MCM Copper Compression Sleeve
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Ilsco
Mfg Catalog # CTL-750
North Coast Part # 1160087


  • UPC Code: 78366915110
  • UNSPSC Code: 39121449
  • Dual Rated: FALSE
  • Conductor Range CU Stranded (Primary, run, main, line): 750 kcmil
  • Conductor Size CU (Primary, run, main, line): 750 kcmil
  • Flex Conductor Range: 600 G,H,I,M 646.4 DLO
  • Flex Conductor Size (Class G): 600 G
  • Flex Conductor Size (Class H): 600 H
  • Flex Conductor Size (Class I): 600 I
  • Flex Conductor Size (Class M): 600 M
  • Flex Conductor Size (Class DLO): 646.4 DLO
  • Expanded Conductor Range: 750 kcmil - 500 kcmil
  • Expanded Conductor Size: 750 kcmil,700 kcmil,650 kcmil,600 kcmil,550 kcmil,500 kcmil
  • Length (IN): 5.875
  • Length (mm): 149.225
  • Width (IN): 1.313
  • Width (mm): 33.3502
  • Height (IN): 1.313
  • Height (mm): 33.3502
  • Weight (LB): 1.175
  • Inside Diameter (IN): 1.031
  • Inside Diameter (mm): 26.1874
  • Outside Diameter (IN): 1.313
  • Outside Diameter (mm): 33.3502
  • Material: Copper
  • Conductor Material: Copper
  • Connector Finish: Tin
  • Color: Silver
  • Die Color Code: Black
  • Direct Burial: FALSE
  • Temperature Rating: 90°C
  • Voltage Rating: 35 kV
  • CSA File Number: LR-29601
  • CSA Standard: C22.2 No. 65-03
  • UL Control Number: 453G
  • UL File Number: E6207
  • UL / CULUS Specification: UL 486A/B Listed
  • NEBS Rating: Level 3
  • Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
  • Barrel Marking: Ink
  • Barrel Type: Long
  • Connection: Compression
  • Connecting angle: 180°
  • Conductor Type: Stranded,Flex
  • Contains DE-OX: FALSE
  • ILSCOs Die Catalog Number: ILD-106
  • Flared End: FALSE
  • Number of Conductors: 1
  • Number of Mounting Holes: 0
  • Sight Window: FALSE
  • Slotted: FALSE
  • Bag Quantity: 1
  • CrossSell: ILD-106, DE-OX-8OZ, TB-6DF1000-P


UPC 78366915110
Item Long Description Surecrimp Copper Compression Sleeve, Long Barrel, Compression connection, Copper material, Tin plated connector,Long barrel, UL 486A/B Listed, C22.2 No. 65-03, 180 connecting angle, Copper Primary Conductor 750 kcmil, 1 conductors, no sight window, flex conductor range 600 G,H,I,M 646.4 DLO, rated for 35 kV, die color code Black, primary color Silver, die index I-106,
GTiN 00783669151107
Length 5.875 in
Voltage 600 Volt
Material Copper
Conductor Size 750 MCM
Applications Copper Compression Sleeve, Long Barrel
Standard CSA File Number: LR-29601,UL Specifications: UL 486A-B,NEBS Rating: LEVEL 3,UL File Number: E6207
Temperature Rating 90 C
Family Brand Name ILSCO
Outside Diameter 1.313 in
Inside Diameter 1.031 in
Color Coding Black
Sub Brand Surecrimp
Finish Tin Plated
Size L:5.875;W:1.313;H:1.313 IN
Color Silver
TC Connection Compression
