ILSCO PED-2-2/0-Z AL MEC 2/0-14 T U

Specifications

• UPC Code: 78366970000
• UNSPSC Code: 39121408
• Dual Rated: TRUE
• Conductor Range CU Stranded (Primary, run, main, line): 2/0 Str - 14 Str
• Conductor Range CU Solid (Primary, run, main, line): 10 Sol - 14 Sol
• Conductor Range AL Stranded (Primary, run, main, line): 2/0 Str - 14 Str
• Conductor Range AL Solid (Primary, run, main, line): 10 Sol - 14 Sol
• Drive Size Main: 16-Mar
• Drive Type Main: Internal Hex
• Number of Wire Binding Screws per Port: 1
• Wire Binding Screw Size: 16-Jul
• Length (IN): 2.091
• Length (mm): 53.1114
• Width (IN): 0.56
• Width (mm): 14.224
• Height (IN): 0.73
• Height (mm): 18.542
• Weight (LB): 0.073256271
• Material: Aluminum
• Conductor Material: Copper,Aluminum
• Connector Finish: Tin
• Wire Binding Hardware Material: Aluminum
• Wire Binding Hardware Finish: Tin
• Color: Silver
• Temperature Rating: 90°C
• Voltage Rating: 600 V
• UL Control Number: 453G
• UL File Number: E6207
• UL / CULUS Specification: UL 486A/B Listed
• Prop65 Compliance: This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
• Connection: Mechanical
• Conductor Type: Solid,Stranded
• Number of Conductors: 2
• Number of Poles: 1
• Number of Ports / Wireways: 2
• Number of Ports Main: 2
• Bag Quantity: 1
• CrossSell: DE-OX-8OZ
