INT-MAT AG48013 277/480V ARRESTER G
Product image thumbnail 0
Product image thumbnail 1
$129.28/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Intermatic
Mfg Catalog # AG48013
North Coast Part # 683449

Features & Applications

Features

  • Three modes of protection
  • TPMOV surge protection technology
  • Green LED protection indicator
  • Type 4X watertight, plastic enclosure for outdoor installations
  • UV-resistant polycarbonate housing
  • 1⁄2" threaded nipple for 7⁄8" nominal conduit knockout
  • 1-year product warranty
  • UL Listed to ANSI/UL 1449 3rd edition
  • CSA certified to ANSI/UL 1449 3rd edition

Applications

  • Light Commercial
  • Outdoor Applications
  • 3-Phase Rooftop HVAC Units

Specifications

  • Voltage Configuration (Single Phase): 277/480 VAC, 50/60 Hz
  • Modes of Protection: 3
  • Surge Protection Type: Type 1, Type 2
  • Nominal Discharge Current: 20 kA
  • Short Circuit Current Rating: 50 kA
  • Surge Protection: TPMOV
  • Wiring Option: Wire Leads
  • Enclosure Type: Indoor/Outdoor Type 4X
  • Maximum Continuous Operating Voltage (L1-L2): 640
  • Maximum Continuous Operating Voltage (L-G): 320
  • Maximum Continuous Operating Voltage (L-L): 640
  • Maximum Continuous Operating Voltage (L-N): 320
  • Voltage Protection Rating (L-G): 1200
  • Voltage Protection Rating (L-L): 2000
  • Voltage Protection Rating (L-N): 1200
  • Operating Temperature Max (°C): 85
  • Operating Temperature Max (F): 185
  • Operating Temperature Min (°C): -35
  • Operating Temperature Min (F): -31
  • Number of Wire Leads: 3
  • Wire Lead Length (in): 18
  • Wire Lead Length (mm): 457.2
  • Product Height (in): 4 3/16
  • Product Height (mm): 106.4
  • Warranty: 1-year

Documents & Downloads

Product Rating



Related Accessories and Parts

  • AG1BRKT: Mounting Bracket for AG2401C3, AG48013, AG2083C3, AG4803C3, AG6503C3, AG6503L3, AG2403C3

Overview

UPC 07827512446
GTiN 00078275124462
Warranty Length 1 yr
Size 1/2 IN, 12.7 MM
Operating Temperature 140 degrees F
Voltage 277/480 Volt
Type Type 1/Type 2 Surge Protective Device
Material PolyCarbonate
Product Series AG
Applications Outdoor - Irrigation Equipment, Farm Equipment, Pumps, Lighting Fixtures, Traffic Signaling Devices, HVACR Controls, Motors
Height 106.4 mm
Standard CSA - UL 1449 3rd Edtion
Connection Type 18 IN Lead
Family Brand Name Intermatic
Number of Phases 1
Enclosure Type Type 4
TC Connection 18 IN Lead
Wire Length 457.2 mm
Max Operating Temperature 185 degrees F
Min Operating Temperature -31 degrees F
Number of Poles 2-1 Pole
Nominal Discharge Current 20 KAMP
