KLEIN VDV826-729 Pass-Thru Data Pl
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Already a Customer? Log in to view your pricing
Manufacturer Klein Tool
Mfg Catalog # VDV826-729
North Coast Part # 1550355


  • Klein exclusive Pass-Thru™ Connectors provide fast, reliable connector installations for data applications
  • CAT6 Cable easily passes through connector to visually ensure that wires are in the correct order for consistent and secure terminations
  • 50µ inch gold plating on all contact surfaces
  • Meets or Exceeds all PoE and PoE+ requirements for performance
  • Category 6 performance per EIA/TIA B.2. FCC compliant, UL rated, RoHS compliant
  • For use with Klein Tools Pass-Thru™ Modular Crimper VDV226-110
  • 10-Pack
  • 8 position, 8 contact Pass Through style data plug for solid or stranded cable
  • Max diameter for CAT6 Pass-Thru™ Connectors is 0.04" (1.01 mm)


  • Do NOT use on energized circuits or cabling systems


  • Package Quantity: 10
  • Overall Length: 0.875" (2.2 cm)
  • Application: Voice and Data
  • Stranded Conductor Wire: Yes
  • Material: PVC Plastic; Gold Plated Contacts
  • Connector Type: RJ45
  • Solid Conductor Wire: Yes
  • Position & Contacts: 8P 8C
  • Overall Height: 0.453" (1.2 cm)
  • Cable Type: CAT6
  • Connector Color: Clear
  • Overall Width: 0.094" (0.2 cm)
  • Weight: 1 oz. (0.03 kg)
  • Type: Modular
  • Special Features: Pass-Thru Technology; Meets All PoE Standards
  • Style_Name: CAT6
  • Size_Name: Quantity 10
  • Accessories: VDV110261,
  • Item Height (in): 0.0920
  • Item Width (in): 0.4590
  • Item Depth (in): 0.8850
  • Item Weight (lbs): 0.0060


UPC 09264469092
GTiN 00092644690921
Family Brand Name Klein Tools
Width 0.459 in
Type Modular
Material PVC
Connector Type RJ45
Applications Voice And Data
Cable Type CAT6
Height 0.092 in
Weight 0.006 in
Pkg Qty 10
Overall Length 0.875 in
CA Prop65 Warning WARNING: Cancer and Reproductive Harm See www.P65Warnings.ca.gov for more information.
Length 0.875 in
Depth 0.885 in
Number of Rows 3
