P&S L920R R SGL 3W20A600V T/L
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$70.35/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Legrand / Pass & Seymour
Mfg Catalog # L920R
North Coast Part # 756487

Features

  • Compact, impact-resistant nylon face and body are ultrasonically welded together for unrivaled strength.
  • Face color coding by voltage facilitates locating and mating of proper devices.
  • One piece, high-grade brass contacts offer excellent conductivity and heat-rise resistance.
  • Clearly marked NEMA configuration, rating, and third-party listing on each unit's face.
  • Single-piece, solid brass mounting strap is free of easily loosened rivets found on other brands.
  • Side and external screw-pressure-plate back wire capability.
  • Accepts #14 - #10 AWG.

Specifications

  • Country Of Origin: MX
  • Special Features: Turnlock, locking device, quick thread assembly, rounded back contour, impact & corrosion resistant, new design external cord grips
  • Certifications: CULUS
  • Phase: 3
  • Amperage: 20 A
  • Product Line: Pass & Seymour
  • Standard: UL 498
  • NEMA Rating: L9-20R
  • Voltage: 600.0 V
  • Wire Size: 10-18Awg
  • Number of Wires: 3.0
  • Application Sector: Commercial
  • Number of Poles: Double Pole

Certifications

  • cULus Listed: 140596

Overview

UPC 78500729205
Item Long Description Turnlok Single Receptacle, 3wire 20amp 600volt, L9-20R
GTiN 00785007292053
Width 1.61 in
Size 3.3"
Color Black/White
Voltage 600 Volt
Type Single Receptacles
Material Thermoplastic
Applications For Commercial Applications
Depth 1.19 in
Height 3.28 in
Country of Origin Mexico
Wire Size 10-18 Awg
Family Brand Name Pass & Seymour
NEMA L9-20R
Amperage 20 Amp
Number of Poles 2 Pole
Number of Wires 3
UNSPSC 39121403
Sub Brand Pass & Seymour
Conductor Size 18-10 AWG
Blade Dimensions 3.3 in L
Number of Phases 3 Phase
Certifications CULUS
