Pass & Seymour PT5262AGRY 15 Amp 125 Volt Gray PlugTail Industrial Extra Heavy Duty Spec Grade Receptacles
Product image thumbnail 0
Product image thumbnail 1
Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Legrand / Pass & Seymour
Mfg Catalog # PT5262AGRY
North Coast Part # 931830


  • .036 inch thick, brass, triple-wipe power contacts for lasting retention.
  • No exposed terminals create a finger safe application before, during, and after installation.
  • Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
  • Crimped and welded contacts.
  • Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
  • Large brass contacts snugly terminate on device blade terminals.
  • Pre-stripped connector leads fasten to conductors, easier than standard pigtails.
  • Auto-ground clip assures positive ground.
  • For covering patents, see
  • For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.


  • Country Of Origin: US
  • Phase: 3
  • Certifications: FEDSPEC,CULUS
  • Amperage: 15 A
  • Color: Gray
  • Standard: UL 498
  • NEMA Rating: 5-15R
  • Product Line: Pass & Seymour
  • Voltage: 125.0 V
  • Wire Size: 10-14Awg
  • Number of Wires: 3.0
  • Application Sector: Commercial
  • Number of Poles: Double Pole
  • Special Features: Plated steel wrap, no exposed terminals, built in connector, crimped & welded contacts


  • Federal Spec Listed
  • cULus Listed


UPC 78500786016
Item Long Description PlugTail Industrial Extra Heavy-Duty Spec Grade Duplex Receptacle 15 A 125 V WhiteFor detailed PlugTail information, visit our PlugTail Headquarters.
GTiN 00785007860160
Width 1.625 in
Size 5x2x1.43
Color Gray
Voltage 125 Volt
Type Receptacles
Material Thermoplastic
Product Series PlugTail
Applications Commercial
Depth .866 in
Height 3.281 in
Grade Industrial
Country of Origin USA
Wire Size 10-14 Awg
Capacity Duplex
Family Brand Name Pass & Seymour
NEMA 5-15R
Certifications CULUS,FEDSPEC
Duty Rating Heavy Duty
Amperage 15 Amp
Number of Poles 2 Pole
Number of Wires 3.0
UNSPSC 39121406
Sub Brand Pass & Seymour
Number of Phases 3 Phase
