Pass & Seymour TR26362-GRY 20 Amp 125 VAC 2-Pole 3-Wire NEMA 5-20R Gray Nylon Tamper-Resistant Duplex Receptacle

Features

• Dual mechanical shutter system to help prevent insertion of foreign objects.
• Auto-ground clip assures positive ground.
• Easily accessed break-off line-contact connecting tab for fast and easy split-circuit wiring.
• Backed-out tri-drive brass terminal screws for faster installation.
• Internal screw-pressure-plate back and side wire capability.
• Two back wire holes for additional wiring flexibility.
• Corrosion-resistant plated steel strap is locked in to face and back body to resist pulling away from the face/body assembly.
• .032 inch thick brass triple-wipe power contacts.
• Two drive screws anchor steel strap to back body and face where abrupt removal torque is greatest.
• For covering patents, see www.legrand.us/patents.
• For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.

Specifications

General Info

• Color: Gray
• Type: Receptacles
• Duty: Heavy Duty
• Special Features: Tamper-Resistant,back,side wire
• Style: Decorator

Listing Agencies/Third Party Certifications

• RoHS: Yes
• CSA Standard: Yes
• cUL Standard: Yes
• Federal Spec: Yes
• UL Listing No: UL498
• UL Standard: Yes
• UN SPSC: 39121406

Dimensions

• Depth (US): 0.833"
• Height (US): 3.281"
• Width (US): 1.322"

Technical Information

• Amps: 20A
• Volts: 125V
• Volts (AC): 125
• Capacity: Duplex
• Grade Type: Federal Specification

Buy American Act Compliance

• Country Of Origin: MEXICO
• Buy American Act Status: Trade Agreement Act Compliant

Eco-Benefit Information

• RoHS Compliant
