LEV 3848-WM TVSS 48V DC TERM BLOCK
$77.10/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Leviton
Mfg Catalog # 3848-WM
North Coast Part # 1024637

Specifications

Material Specifications

  • Case Material: Polycarbonate
  • DIN-Rail Material: Polycarbonate

Standards and Certifications

  • Warranty: 10-Year Limited
  • UL: 497B Listed
  • CSA: C22.2

Performance Data

  • Maximum Surge Current 10 x 1000μsec: 10A
  • Maximum Capacitance: 4.8μf
  • Maximum DC Operating Voltage: 52.8V
  • UL497B Clamping: 71V
  • Voltage: 48 VDC
  • Breakdown Voltage 100V/μsec: 51.8 - 71.8 V

Environmental Specifications

  • Altitude: 15,000 ft
  • Storage Temperature: -20°C to 85°C
  • Operating Temperature: -10°C to 60°C
  • Relative Humidity: 20% to 90% non-condensing

Categories

Overview

UPC 07847795910
GTiN 00078477959107
Warranty Length 10 yr
Size 3.78 H x 1.66 W x 1.58 D IN
Operating Temperature -10 C
Voltage 48 Volt
Type Low Voltage SPD
Material Polycarbonate
Applications Industrial
Standard CSA Certified (C22.2),ISO (9001:200),UL Listed (497B)
Connection Type Standard Equipment Mount,Terminal Block
Family Brand Name Leviton
TC Connection Terminal Block;Standard Equipment Mount
Environmental Conditions Altitude (15000 FT),Humidity (20% To 95% Non-Condensing),Storage Temperature (-20 To 85 DEG C)
CSA C22.2
Storage Temperature -20 To 85 C
