LEV 55240-ASA VSS
$248.41/ea
In Stock | 2 available at 2 locations
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Leviton
Mfg Catalog # 55240-ASA
North Coast Part # 752755

Specifications

Material Specifications

  • Enclosure: Polycarbonate with UV inhibitors

Warranty

  • Warranty: 5-Year Limited
  • Connected Equipment Coverage: Up to $10,000

Standards and Certifications

  • National Electric Code (NEC): 285
  • ETL Certified: UL 1449 3rd Ed, Type 1 Device
  • ANSI/IEEE Category C: C-62.11, C-62.41 & C-62.45

Performance Data

  • MCOV: 150V
  • Voltage Protection Rating (VPR) (Clamping) L-N/L-L: 600V/800V
  • Nominal Discharge Current Rating: 20kA
  • Maximum Surge Current, Per Mode (Per Phase): 50kA (50kA)

Mechanical Specifications

  • Diagnostics: Protection Status LEDs & Audible Alarm
  • Enclosure: Type 3R
  • Connection Type: Parallel Connection: Hardwired via 10AWG wire

Electrical Specifications

  • Surge Technology: TPMOV
  • Frequency: 50/60Hz
  • Voltage: 120/240 VAC

Environmental Specifications

  • Flammability: Rated V-2 per UL 94
  • Operating Temperature: -10°C to 60°C
  • Storage Temperature: -20°C to 85°C

Categories

Overview

UPC 07847751647
GTiN 00078477516478
Warranty Length 5 yr
Size 3.13 H x 3.13 W x 3D IN
Operating Temperature -10 C
Voltage 120/240 Volt
Type Type 1, Parallel, 1-Phase
Material Polycarbonate
Applications Commercial
Standard ANSI\IEEE (Category C-62.11, C-62.41, C-62.45),NEC (285),NEMA
Frequency 50/60 Hz
Connection Type Parallel Connection
Family Brand Name Leviton
NEMA 3R
Number of Phases 1 Phase
Enclosure Type Polycarbonate With UV Inhibitors
Flamability Class Rated V-2 Per UL 94
TC Connection Parallel Connection;Hardwired via 10AWG wire
Environmental Conditions Humidity (5 To 95 Non-Condensing) %
Storage Temperature -20 To 85 C
Temperature Rating -10 to 60 C Operating, -20 to 85 C Storage
Blade Dimensions 3.13 in W x 3 in D x 3.13 in H
