Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Leviton
Mfg Catalog # OSSMT-GTW
North Coast Part # 940440


Product Features

  • Code Compliance: California Title 24
  • ON/OFF Configurations: Manual ON/Auto OFF
  • Power Pack: External Power Pack Not Required
  • Mounting: Wall Switch
  • Relative Humidity: 20% to 90% non-condensing
  • Device Type: Vacancy Sensor
  • Operating Temperature: 0°C to 50°C
  • Coverage (Sq.Ft.): 2400 Sq. Ft.
  • Switch Type: Single-Pole
  • Standards and Certifications: UL/cUL
  • Country Of Origin: Mexico
  • Neutral Wire Connection: Not Required
  • Photocell: Internal
  • Pattern: 180°
  • Time Delay: 30s-30m
  • Consumption (mA): N/A
  • Wallplate: Order Separately
  • Warranty: 5-Year Limited
  • Storage Temperature Range: -10°C to 85°C
  • Color: White
  • HVAC Relay: N/A
  • Load Rating: 800W@120V INC 1200VA@120V 2700VA@277V FL
  • Grade: Commercial Specification Grade
  • LED Color: Green and Red
  • Voltage: 120/277 VAC
  • Motor: 1/4 HP @ 120V
  • Product Line: OSSMT
  • Mounting Height (Ft.): 4 Ft.
  • Adjustment: Self-Adjusting
  • Technology: Multi-Technology PIR/Ultrasonic
  • Size: 4.06" H x 1.75" W x 1.85" D (103.2mm x 44.4mm x 47.2mm)


UPC 07847761231
Item Long Description Manual ON Multi-Tech Wall Box Vacancy Sensor w/No Neutral Wire 120/208/220/230/240/277V 50/60Hz CEC Title 24 Compliant 30s-30m Time Delays Ambient Light Override Self Adjusting Field Configurable White NAFTA Compliant.
GTiN 00078477612316
Warranty Length 5 yr
Size 46 H x 1.75 W x 1.85 D IN
Color White
Operating Temperature 0 C
Voltage 120 Volt
Type Single-Pole Switch,Vacancy Sensor
Applications Commercial
Mounting Type Wall
Grade Commercial Specification
Country of Origin Mexico
Standard CEC Title 24 Compliant,CUL Listed,ETL\cETL Listed,FCC Compliant,NAFTA (CF434),NYCL48,Title 20,UL Listed
Frequency 50/60 Hz
Switch Type Single-Pole
Family Brand Name Leviton
Certifications UL/cUL
Power Consumption 120 V
Environmental Conditions Humidity (20 To 90 Non-Condensing) %
LED Color Green,Red
Device Type Vacancy Sensor
Coverage 2400 sq-ft
Storage Temperature -10 To 85 C
Sub Brand Decora
