LEV T5632-E 5-15R USB COMBINATION R
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$45.69/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Leviton
Mfg Catalog # T5632-E
North Coast Part # 1014859

Features

  • Perfect for use in residential applications such as kitchens, bedrooms and home offices and in commercial applications such as hotels, airports, restaurants and cafes, salons, office cubicles and college dorm rooms
  • Smart chip recognizes and optimizes the charging requirements of individual devices
  • USB Ports are positioned vertically providing more space for maneuvering and reducing stress on USB cables
  • Compatible with USB 3.0, 2.0, 1.1 devices
  • Fits in a standard wallbox, is compatible with standard wallplates and can be multi-ganged with other devices
  • Easy to install. Can replace existing outlets
  • No data transfer capability
  • SMART - Built-in smart chip recognizes the individual device’s charging requirement to optimize the charge
  • POWERFUL – Two high-powered charging ports with 3.6A of charging power
  • CONVENIENT – No more searching for charging adapters! Upgrade your existing outlets so you can charge up to two USB powered electronics at once, leaving the outlets free for additional power needs
  • EASY - Compact design fits in a standard wallbox and works with Decora and Decora Plus screwless wallplates.

Specifications

Material Specifications

  • Amperage: 15 A
  • Product ID: Stamped on Strap
  • Terminal Accom.: 14-12 AWG
  • Color: Black
  • Cover Material: Thermoplastic
  • Strap Material: Steel
  • Torque Range: 12-14 inch pounds
  • Body Material: Thermoplastic
  • Termination: Back & Side

Standards and Certifications

  • Warranty: 5-Year Limited
  • NOM: 057
  • UL 1310: Yes
  • UL 498: Yes
  • FCC Part 15: Class B
  • Listed: cCSAus

Product Features

  • Amperage: 15 A
  • Ratings: 15A-125V
  • NEMA: 5-15R
  • Grade: Residential/Commercial Specification Grade
  • Brand: Decora
  • Country Of Origin: China
  • Voltage: 125 VAC
  • Grounding: Grounding
  • Horsepower Rating: 15A-1/2 HP
  • Product Type: Outlet/USB Combo
  • Type: Type A/A Duplex Receptacle

Mechanical Specifications

  • Amperage: 15 A
  • Product ID: Stamped on Strap
  • Terminal Accom.: 14-12 AWG
  • Torque Range: 12-14 inch pounds
  • Color: Black
  • Grade: Residential/Commercial Specification Grade
  • Termination: Back & Side

Electrical Specifications

  • Amperage: 15 A
  • Flammability: Rated V-0 per UL 94
  • Ratings: 15A-125V
  • Operating Temperature: -10°C to 40°C
  • Grounding: Grounding
  • Horsepower Rating: 15A-1/2 HP

Environmental Specifications

  • Flammability: Rated V-0 per UL 94
  • Color: Black
  • Cover Material: Thermoplastic
  • Strap Material: Steel
  • Operating Temperature: -10°C to 40°C
  • Body Material: Thermoplastic

videos

Overview

GTiN 00078477683927
Warranty Length 5 yr
Color Black
Operating Temperature -10 C
Voltage 125 Volt
Type Type A/A Duplex Receptacle
Product Type Outlet/USB Combo
Applications Commercial/Residential
Mounting Type Surface, Claw and Screw
Grade Residential/Commercial Specification
Country of Origin China
Standard CCSAus
Torque 12-14 lb-in
Horsepower 1/2 hp
Body Material Thermoplastic
Family Brand Name Leviton
NEMA 5-15R
Flamability Class Rated V-0 Per UL 94
Grounding Grounding
Amperage 15 Amp
Blade Dimensions 44 mm W x 42.5 mm D x 102.7 mm H
Cover Material Thermoplastic
Product UPC 07847768392
