Manufacturer Lutron
Mfg Catalog # DV-603PG-WH
North Coast Part # 492537

Features

  • Controls 600 W incandescent or halogen loads
  • Paddle turns on/off
  • Slide up to brighten, down to dim
  • Guarantees at least 15 percent energy savings compared to a standard switch.

Specifications

  • Wattage: 600 W
  • Sub Brand: Diva
  • Mounting: Wallbox
  • Standard: UL, CSA
  • Brand Name: Lutron
  • Enclosure: Plastic
  • Number Of Poles: 1
  • Insulation: Plastic
  • Voltage Rating: 120 V
  • Connection: Wire Leads
  • Actuator: Paddle switch
  • Material: Plastic/Metal
  • Application: Lighting Control
  • Frequency Rating: 50 to 60 Hz
  • Pack Description: Box
  • Pack Type: EA
  • Number of Sub Packs: 1
  • Total Units Imperial: 1 EA
  • Gross Weight per Pack Imperial: 0.28 L
  • Length Imperial: 2.25 IN
  • Width Imperial: 2.25 IN
  • Height Imperial: 4.5 IN
  • Size: 4.69 in (119 mm) x 2.94 in (75 mm)
  • Type: Dimmer, 3-way/single-pole, with eco-dim
  • Operating Temperature: 0 to 40 degrees Celsius
  • Country of Origin: CN

Categories

Overview

UPC 02755758946
Item Long Description Diva Dimmer - Gloss Finish, Incandescent/Halogen, 3-way/single-pole, eco-dim with locator light, 120V/600W in white
GTiN 00027557589468
Size 4.69 in (119 mm) x 2.94 in (75 mm)
Color White
Operating Temperature 0 - 40 C
Voltage 120 Volt
Type Paddle, 3-Way
Material Metal/Plastic
Applications Lighting Control
Mounting Type Wallbox
Country of Origin China
Standard CSA,UL
Frequency 50 Hz
Connection Type Wire Lead
Wattage 600 Watt
Family Brand Name Lutron
Insulation Material Plastic
Power Rating 600 W
TC Connection Wire Leads
Actuator Paddle Switch
Blade Dimensions 75 mm W x 119 mm H
Enclosure Material Plastic
Number of Poles 1 Pole
Enclosure Plastic
Sub Brand Diva
