LUT EC3DT418KU1S ECOSYS BST-3W/ECO
$180.80/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Lutron
Mfg Catalog # EC3DT418KU1S
North Coast Part # 882877

Features

  • Provides high-performance dimming for any compact fluorescent application
  • Offers continuous flicker-free dimming from 100% to 5 %, providing both energy savings and lighting flexibility
  • Compatible with Energi Savr Node with EcoSystem devices, GRAFIK Eye QS with EcoSystem connection, PowPak dimming module with EcoSystem connection, and Quantum systems, allowing for integration into an existing/planned EcoSystem lighting control system
  • Supports standard 3-wire line-voltage phase control technology
  • Programmed rapid start design ensures full-rated lamp life while dimming and cycling
  • Lamps turn on to any dimmed level without flashing to full brightness
  • Low harmonic distortion throughout the entire dimming range
  • Frequency of operation ensures that ballast does not interfere with infrared devices
  • Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing, and relay failure
  • Ultr-quiet operation
  • Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground
  • End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life
  • Nonvolatile memory restores all ballast settings after power failure
  • 100% compatible with all Lutron 3-wire fluorescent controls and EcoSystem digital controls
  • 100% performance tested at factory
  • Custom ballast factors available
  • Design tool and specifications can be found at www.lutron.com/ballasttool

Specifications

  • Color: White
  • Type: Ballast
  • Wattage: 18 W
  • Mounting: Fixture
  • Start Type: Rapid
  • Brand Name: Lutron
  • Dimmable: Dimmable
  • Number Of Lamps: 1
  • Width: 3 in (76 mm)
  • Ballast Factor: 0.95
  • Sub Brand: EcoSystem
  • Length: 4.9 in (124 mm)
  • Frequency Rating: 50/60 Hz
  • Height: 1.29 in (25.74 mm)
  • Thermal Protection: Class P
  • Pack Description: Box
  • Pack Type: EA
  • Number of Sub Packs: 1
  • Total Units Imperial: 1 EA
  • Gross Weight per Pack Imperial: 0.6 L
  • Length Imperial: 3 IN
  • Width Imperial: 4.8 IN
  • Height Imperial: 1.3 IN
  • Application: Lighting Control
  • Power Factor: Greater than 0.95
  • Voltage Rating: 120/220/240/277 V
  • Total Harmonic Distortion: Less than 10%
  • Minimum Starting Temperature: 10 degrees Celsius
  • Standard: UL, CSA, Class P thermal protected, ANSI, FCC
  • Lamp Type: T4 4-Pin Quad tube or Triple tube Fluorescent
  • Amperage Rating: 0.18@120 V/0.10@220V/0.09@240V/0.08@277V
  • Country of Origin: MX

Overview

UPC 02755763867
GTiN 00027557638678
Length 4.9 in
Width 3 in
Color White
Voltage 277 Volt
Type Dimmable
Applications Lighting Control
Mounting Type Fixture
Height 1.29 in
Country of Origin Mexico
Standard CSA,FCC,Class P Thermal Protected,ANSI,UL
Frequency 60 Hz
Wattage 18 Watt
Family Brand Name Lutron
Lamp Type T4 4-Pin Quad or Triple Tube Fluorescent
Number of Lamps 1
Dimmable? Yes
Amperage 0.18 Amp
Min Temperature 10 C
Blade Dimensions 124 mm L x 76 mm W x 25.74 mm H
Start Type Rapid
Minimum Starting Temp 10 C
Power Factor < 0.95
Ballast Factor 0.95
Thermal Protection Class P
Total Harmonic Distortion > 10%
Sub Brand EcoSystem
