LUT MA-FQ4FM-BR MA FAN MLOC W/1 CM

$77.40/ea

Usually ships within 11 to 17 Days

Adding...

Already a Customer? Log in to view your pricing

Details

Remote control versions available
One canopy module included with main control; order one canopy module for each additional fan controlled
Coordinating Claro wallplates available separately
7 quiet fan speeds; the LEDs correspond to the fan speed
Multi-location dimming compatible with 3-way wiring for easy installation and retrofit
Available in 27 colors
Controls up to four fans
Matching dimmers, switches, and accessories available
Use up to 2 companion controls with one Maestro digital fan control
Use the rocker to adjust fan speed

Set multi-speed fans to their highest setting before installing controls.
In multi-location applications, only one dimmer can be used.
Can be used with up to four 1A ceiling fans. Do not use with exhaust fans.
Do not use incandescent, halogen or compact fluorescent lamps or electronic low voltage lighting.

UPC	02755723546
GTiN	00027557235464
Size	4.69 in (119 mm) x 2.94 (75 mm)
Color	Brown
Voltage	120 Volt
Type	Multi-location/single-pole,With Canopy Module,Digital Fan Control
Applications	Fan Control
Mounting Type	Wallbox
Standard	UL CSA NOM
Connection Type	Screw Terminals
Wattage	480 Watt
Family Brand Name	Lutron
Control Type	Main Control
TC Connection	Screw terminal
Actuator	Tapswitch
Contact Configuration	N-O
Amperage	4 Amp
Enclosure Material	Plastic
Contact Rating	1 A
Number of Poles	1 Pole
Enclosure	Plastic
Sub Brand	Maestro
