Lutron MA-L3L3-WH 300 W 120 Volt White 1-Pole Incandescent/Halogen Digital Fade Dimmer
$83.19/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Lutron
Mfg Catalog # MA-L3L3-WH
North Coast Part # 347289

Features

  • Controls 300 W incandescent or halogen loads
  • Dimmers (top/bottom)
  • Replacement for stacked switches
  • Tap on to preset light level; tap off
  • Tap twice for full on
  • Touch rocker to adjust light level
  • Single location only
  • Dimmer advanced programming features available.

Specifications

  • Wattage: 300 W
  • Standard: UL cUL
  • Mounting: Wallbox
  • Brand Name: Lutron
  • Enclosure: Plastic
  • Number Of Poles: 1
  • Sub Brand: Maestro
  • Actuator: Tapswitch
  • Insulation: Plastic
  • Voltage Rating: 120 V
  • Material: Plastic/Metal
  • Connection: Screw terminals
  • Application: Lighting Control
  • Frequency Rating: 50 to 60 Hz
  • Pack Description: Box
  • Pack Type: EA
  • Number of Sub Packs: 1
  • Total Units Imperial: 1 EA
  • Gross Weight per Pack Imperial: 0.28 L
  • Length Imperial: 2.25 IN
  • Width Imperial: 3.375 IN
  • Height Imperial: 4.5 IN
  • Size: 4.69 in (119 mm) x 2.94 in (75 mm)
  • Operating Temperature: 0 to 40 degrees Celsius
  • Type: Dual digital-face dimmer (two loads), single-pole
  • Environmental Conditions: 0 to 90% humidity, non-condensing
  • Country of Origin: MX

Overview

UPC 02755741137
GTiN 00027557411370
Size 4.69 in (119 mm) x 2.94 in (75 mm)
Color White
Operating Temperature 0 - 40 C
Voltage 120 Volt
Type Turn/Push Button, Dual Digital Fade
Material Plastic
Applications For Incandescent/Halogen Lighting Control
Mounting Type Wallbox
Country of Origin Mexico
Standard UL CUL
Frequency 60 Hz
Connection Type Screw Terminal
Wattage 300 Watt
Family Brand Name Lutron
Insulation Material Plastic
Power Rating 300 W Incandescent/Halogen
TC Connection Screw terminals
Actuator Tapswitch
Max Wattage 300 W
Blade Dimensions 2.94 in W x 4.69 in H
Environmental Conditions 0 - 90% RH Non-Condensing
Enclosure Material Plastic
Number of Poles 1 Pole
Enclosure Plastic
Bulb Compatibility Incandescents,Halogens
Sub Brand Maestro
