LUT V-1000-IV VAREO 1000VA INC/LOW
Product image thumbnail 0
Product image thumbnail 1
$198.43/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Lutron
Mfg Catalog # V-1000-IV
North Coast Part # 264338

Details

  • One model number for single pole or 3-way, incandescent or magnetic low-voltage
  • Incandescent/halogen and magnetic low voltage models available
  • Includes wallplate
  • Large tap switch and discreet slide dimmer
  • Matching switches available
  • Sophisticated thin profile
  • Available in 10 colors
  • For multi-location switching, use VETS-R companion switch
  • Heavy duty components for surge protection and long product life
  • Controls up to 1000W

Specifications

  • Dimmer Wattage Capacity: Up to 1000 Watts
  • Color: Ivory

Matte Finish Color

Ivory (IV)

Additional Product Information

  • In multi-phase applications, use a separate neutral with each phase containing a control circuit.
  • Cannot use with 3-way or 4-way switches.
  • In multi-location applications, only one dimmer can be used.
  • Use dimmer with core and coil low voltage transformers.
  • Connect only No. 12 or 14 gauge copper or copper-clad wire to this device. Do not connect aluminum wire to this device. See device for strip length.
  • Do not use with compact fluorescent lamps .
  • Do not connect to receptacles, fluorescent fixtures, motor-operated appliances or transformer-supplied appliances.
  • Do not use for electronic low voltage lighting.

Overview

UPC 02755768883
GTiN 00027557688833
Size 4.56 in (116 mm) x 2.75 in (70 mm)
Color Ivory
Operating Temperature 0 to 40 C
Voltage 120 Volt
Type Multi-location/single-pole,Preset Dimmer
Material Metal,Plastic
Applications Lighting Control
Mounting Type Wallbox
Standard UL CSA NOM ISO 9001
Frequency 60 Hz
Connection Type Wire Leads
Wattage 1000 Watt
Family Brand Name Lutron
Insulation Material Plastic
TC Connection Wire Leads
Actuator Tapswitch
Enclosure Material Plastic
Number of Poles 1 Pole
Enclosure Plastic
Sub Brand Vareo
