Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Lutron
Mfg Catalog # V-600-GR
North Coast Part # 349380


  • Controls up to 1000W
  • Available in 10 colors
  • Large tap switch and discreet slide dimmer
  • Heavy duty components for surge protection and long product life
  • Includes wallplate
  • One model number for single pole or 3-way, incandescent or magnetic low-voltage
  • Matching switches available
  • Sophisticated thin profile
  • Incandescent/halogen and magnetic low voltage models available
  • For multi-location switching, use VETS-R companion switch


  • Dimmer Wattage Capacity: Up to 600 Watts
  • Color: Gray

Matte Finish Color

Gray (GR)

Additional Product Information

  • In multi-location applications, only one dimmer can be used.
  • Do not use with compact fluorescent lamps .
  • Do not connect to receptacles, fluorescent fixtures, motor-operated appliances or transformer-supplied appliances.
  • Connect only No. 12 or 14 gauge copper or copper-clad wire to this device. Do not connect aluminum wire to this device. See device for strip length.
  • Use dimmer with core and coil low voltage transformers.
  • Cannot use with 3-way or 4-way switches.
  • Do not use for electronic low voltage lighting.
  • In multi-phase applications, use a separate neutral with each phase containing a control circuit.


GTiN 00027557688741
Size 4.56 in (116 mm) x 2.75 in (70 mm)
Color Gray
Operating Temperature 0 to 40 C
Voltage 120 Volt
Type Multi-location/single-pole,Preset Dimmer
Material Metal
Applications Lighting Control
Mounting Type Wallbox
Standard UL CSA NOM ISO 9001
Frequency 60 Hz
Connection Type Wire Leads
Wattage 600 Watt
Family Brand Name Lutron
Insulation Material Plastic
TC Connection Wire Leads
Actuator Tapswitch
Enclosure Material Plastic
Number of Poles 1 Pole
Enclosure Plastic
Sub Brand Vareo
Product UPC 02755768874
