FERRAZ 30607T 67530-FB 2P 300V-60A

Features

• Unique integral DIN-rail adapters for 600V, 30 & 60A blocks
• Full barrier design (30 & 60A) increases pole to pole safety
• Unique adder-block design (30 & 60A) for design flexibility
• Spring reinforcing standard for all 30 & 60A clips
• Features high conductivity copper alloy fuse clips
• Cool running high amperage (100 - 600A) connectors
• Copper connectors available 30 - 600A

Approvals & Standards

• All fuse blocks meet the requirements of UL 4248
• UL listed, guide IZLT, File E52283
• UL recognized component guide IZLT2, file E52283
• CSA certified class 6225, File 32169

Specifications

• Rated voltage AC UL: 300 V
• Rated voltage DC UL: 300 V
• Ampere Rating: 60 A
• ROHS Compliant: Yes
• Fuse Class: Class T
• Short Circuit Current Rating (SCCR): 200
• Fuse Type/Class: Class T
• Number of Poles: 2-pole
• Fuse Installation Method: Clip-in
• Body/Insulating Material: GFPC
• Max Fuse Rating: 60 A
• Installation Mounting: Direct Screw Mount

Product Dimensions

• Product Weight: 0.29 lb
• Product Width: 0.98 in
• Product Length: 3.37 in
• Product Height: 1.47 in

Packaging Dimensions

• Sell Pack Quantity: 5 Each
• Sell Pack Weight: 1.52 lb
• Sell Pack Width: 5.12 in
• Sell Pack Length: 8.44 in
• Sell Pack Height: 2.44 in
