FERRAZ 60322J 600V 30A J 2P FUSE BL
Product image thumbnail 0
Product image thumbnail 1
$47.36/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # 60322J
North Coast Part # 665590

Features

  • Class J Blocks (600V) use with AJT, A4J, HSJ

Approvals & Standards

  • All class J fuse blocks meet the requirements of UL4248 (formerly UL512)
  • UL listed Guide IZLT, File E52283
  • CSA certified class 6225, File 32169

Specifications

  • Rated voltage AC UL: 600 V
  • Rated voltage DC UL: 600 V
  • Ampere Rating: 30 A
  • ROHS Compliant: Yes
  • Fuse Class: Class J
  • Short Circuit Current Rating (SCCR): 200
  • Fuse Type/Class: Class J
  • Number of Poles: 2-pole
  • Fuse Installation Method: Clip-in
  • Body/Insulating Material: GFPC
  • Max Fuse Rating: 30 A
  • Installation Mounting: Direct Screw Mount

Product Dimensions

  • Product Weight: 0.414 lb
  • Product Width: 3.15 in
  • Product Length: 4 in
  • Product Height: 2.12 in

Packaging Dimensions

  • Sell Pack Quantity: 5 Each
  • Sell Pack Width: 4.88 in
  • Sell Pack Length: 10.75 in
  • Sell Pack Height: 3.38 in

Overview

UPC 78200175862
Family Brand Name Ferraz Shawmut
GTiN 00782001758622
Length 4 in
Width 3.15 in
Type Open Style
Mounting Type Direct Screw Mount
Height 2.12 in
Weight 0.414 lb
Pkg Qty 5
Class J
Insulation Material GFPC
TC Connection Box
Amperage 30 Amp
Fuse Interrupt Rating 30 A
Number of Poles 2 Pole
Rated Voltage AC 600 V
Rated Voltage DC 600 V
Fuse Class Class J
Voltage 600 VAC
Fuse Type Class J
