FERRAZ A072B1DAR0-6R 7.2KV 6R R RAT
$3,202.19/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # A072B1DAR0-6R
North Coast Part # 602875

Features

  • The Amp-Trap Bolt-in series are UL Recognized
  • Bolt-in mounting for direct connection to bus or terminals
  • Current-limiting for superior equipment protection
  • Metal embossed catalog number and manufacturing date for lasting identification
  • Blown-fuse indicator to give positive identification of open fuse
  • Amp-Trap: 3" Barrel 2 lb tripped force - 0.50 Inch

Applications

  • Short circuit protection of medium voltage motors and motor controllers

Approvals & Standards

  • UL Recognized File E93367

Specifications

  • Rated voltage AC UL: 7200 V
  • Frequency: 50/60 Hz
  • ROHS Compliant: Yes
  • Speed/Characteristic: R-Rated
  • Mounting: Bolted
  • AC Max I.R./Breaking Capacity: I1: 50 kA
  • Indication System: Yes
  • Indication System Type: Visual Indicator
  • Connection/Terminal Material: Silver-Plated Copper
  • Connection/Terminal Type: Bolted
  • Body/Insulating Material: GMG

Product Dimensions

  • Product Weight: 12 lb
  • Product Diameter: 3 in
  • Product Width: 3 in
  • Product Length: 19.25 in
  • Product Height: 3.63 in

Packaging Dimensions

  • Sell Pack Quantity: 1 Each
  • Sell Pack Weight: 12.6 lb
  • Sell Pack Width: 5.5 in
  • Sell Pack Length: 28.12 in
  • Sell Pack Height: 4.5 in

Categories

Overview

UPC 78200180519
Family Brand Name Ferraz Shawmut
GTiN 00782001805197
Length 19.25 in
Width 3 in
Size 3 x 19.25 Inches
Type Back-up current-limiting fuses R-Rated
Diameter 3 in
Material bolt-on
Terminal Type Bolted
Applications Short circuit protection of medium voltage motors and motor controllers.
Mounting Type Bolted
Height 3.63 in
Weight 12 lb
Pkg Qty 1
Insulation Material GMG
TC Connection bolt-on
Response Time R-Rated
Interrupt Rating 50 kA
Indicator Visual Indicator
Terminal Material Silver-Plated Copper
Rated Voltage AC 7200 V
Voltage null
Frequency 50 Hz
