FERRAZ A155B2D0R0-9R 15.5kV 9R R-RA
Product image thumbnail 0
Product image thumbnail 1
Usually ships within 8 to 12 Days
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # A155B2D0R0-9R
North Coast Part # 602976


  • The Amp-Trap Bolt-in series are UL Recognized
  • Bolt-in mounting for direct connection to bus or terminals
  • Current-limiting for superior equipment protection
  • Metal embossed catalog number and manufacturing date for lasting identification
  • Blown-fuse indicator to give positive identification of open fuse


  • UL Recognized File E93367


  • Amp-Trap: 3" Barrel 2 lb tripped force - 0.50 Inch
  • Max Operating Temp: 80 °C
  • Max Storage Temp: 80 °C
  • Min Storage Temp: -25 °C
  • Rated Voltage Ac Ul: 15500 V
  • Ac Max I R Breaking Capacity I1: 50 kA
  • Country Of Origin: MX
  • Product Line: 15.5 kV Bolt-On Mount Motor
  • Product Brand: Amp-Trap®
  • Body Insulating Material: GMG
  • Connection Terminal Material: Silver-Plated Copper
  • Connection Terminal Type: Bolted
  • Speed Characteristic: R-Rated
  • Mounting: Bolted


UPC 78200135944
Family Brand Name Ferraz Shawmut
Item Long Description Mersen R-Rated fuses are current-limiting, high interrupting rating fuses intended for the short circuit protection of medium voltage motors and motor controllers. R-Rated fuses are back-up fuses that have a minimum interrupting rating, and must be coordinated with overload relays in combination motor starters. The motor starter manufacturer generally specifies the R-Rated fuse size. These fuses are single, double, triple or quadruple barrels 3 inches diameter with end mounts designed for bolting directly to equipment bus or terminal pads
GTiN 00782001359447
Length 25.1 in
Width 3 in
Type Back-up Current-limiting Fuses R-Rated
Terminal Type Bolted
Applications Protection for 15.5kV Motors
Mounting Type Bolted
Height 7.63 in
Weight 29 lb
Pkg Qty 1
Insulation Material GMG
TC Connection Bolt-on
Indicator Visual Indicator
Terminal Material Silver-Plated Copper
Rated Voltage AC 15500 V
Frequency 50 Hz
Voltage 15500 Volt
Country of Origin Mexico
Max Operating Temperature 80 C
