FERRAZ A60C250-121TI 93512-FUSE,FOR
Product image thumbnail 0
Product image thumbnail 1
$642.19/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # A60C250-121TI
North Coast Part # 494649

Features

  • High interrupting rating
  • Current-limiting
  • Capacitor inrush withstand capability
  • Direct mount
  • Optional blown fuse indication

Applications

  • Advanced safety for power correction and harmonic filtering equipment

Approvals & Standards

  • UL Recognized Component File E60314
  • Tested by UL to CSA standard C22.2 No. 248.1

Specifications

  • Rated voltage AC UL: 600 V
  • Ampere Rating: 250 A
  • Mounting: Direct Mount
  • AC Max I.R./Breaking Capacity: I1: 200 kA
  • Indication System: Yes
  • Indication System Type: TI Indicator
  • Connection/Terminal Material: Silver-Plated Brass
  • Connection/Terminal Type: Screw-in
  • Body/Insulating Material: GMG

Product Dimensions

  • Product Weight: 0.65 lb
  • Product Diameter: 1.22 in
  • Product Length: 3.82 in

Packaging Dimensions

  • Sell Pack Quantity: 5 Each
  • Sell Pack Weight: 3.41 lb
  • Sell Pack Width: 4.12 in
  • Sell Pack Length: 2.75 in
  • Sell Pack Height: 5.94 in

Overview

UPC 78200193512
Family Brand Name Ferraz Shawmut
GTiN 00782001935122
Length 3.82 in
Type Low-Voltage Capacitor Fuses
Diameter 1.22 in
Terminal Type Screw-in
Applications For the protection of Capacitors
Mounting Type Direct Mount
Weight 0.65 lb
Pkg Qty 5
Insulation Material GMG
TC Connection Screw-in
Amperage 250 Amp
Interrupt Rating 200 kA
Indicator TI Indicator
Terminal Material Silver-Plated Brass
Rated Voltage AC 600 V
Voltage 600 VAC
