FERRAZ A70Q100-4IL 700V 100A SEMICO

Features

• Lowest I2t of any fuse in this voltage rating for best overall protection
• 700V AC, 650V DC rating allows protection of greater variety of circuits
• Solid fill technology for extra reliability in performance

Applications

• Protection of inverters and other equipment requiring the best AC or DC protection in this voltage range

Approvals & Standards

• UL recognized component UL File E60314
• AC: guide no. JFHR2
• DC: tested to UL standard 198L parameters (35-600A)

Specifications

• Rated voltage AC UL: 700 V
• Rated voltage DC UL: 650 V
• Ampere Rating: 100 A
• ROHS Compliant: Yes
• Speed/Characteristic: High Speed
• Mounting: Bolted
• AC Max I.R./Breaking Capacity: I1: 50 kA
• Indication System: Yes
• Indication System Type: IL Indicator
• Connection/Terminal Material: Tin-Plated Brass
• Connection/Terminal Type: Bolted
• Body/Insulating Material: GMG

Product Dimensions

• Product Weight: 0.57 lb
• Product Diameter: 1.22 in
• Product Length: 4.37 in

Packaging Dimensions

• Sell Pack Quantity: 5 Each
• Sell Pack Width: 5.19 in
• Sell Pack Length: 13.5 in
• Sell Pack Height: 3.31 in
