FERRAZ CNL325 FORK LIFT TRUCK FUSE
Product image thumbnail 0
Product image thumbnail 1
$69.67/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # CNL325
North Coast Part # 151716

Features

  • All fuses are AC and DC rated
  • Expanded ampere ratings
  • Time-delay and general purpose types
  • Link is visible through window

Applications

  • Forklift trucks
  • Battery hand trucks
  • Motorized work platforms
  • Battery systems

Approvals & Standards

  • UL recognized components (All Products) File E60314

Specifications

  • Rated voltage DC UL: 80 V
  • Ampere Rating: 325 A
  • ROHS Compliant: Yes
  • Mounting: Bolted
  • AC Max I.R./Breaking Capacity: I1: 2500 A
  • Indication System: Yes
  • Indication System Type: Visual Indicator
  • Connection/Terminal Material: Silver-Plated Copper
  • Connection/Terminal Type: Blade
  • Body/Insulating Material: GMG

Product Dimensions

  • Product Weight: 0.04 lb
  • Product Width: 0.63 in
  • Product Length: 3.19 in
  • Product Height: 0.63 in

Packaging Dimensions

  • Sell Pack Quantity: 5 Each
  • Sell Pack Weight: 0.21 lb
  • Sell Pack Width: 3.35 in
  • Sell Pack Length: 1.03 in
  • Sell Pack Height: 3.35 in

Overview

UPC 78200179076
Family Brand Name Ferraz Shawmut
GTiN 00782001790769
Length 3.19 in
Width 0.63 in
Type Forklift Truck Fuses
Terminal Type Blade
Applications For Forklift Trucks, Battery Hand Trucks, Motorized Work Platforms, Battery Systems
Mounting Type Bolt-On
Height 0.63 in
Weight 0.04 lb
Pkg Qty 5
Insulation Material GMG
Amperage 325 Amp
Interrupt Rating 2.5 kA
Indicator Visual Indicator
Terminal Material Silver-Plated Copper
Rated Voltage DC 80 V
Voltage 80 VAC
