FERRAZ CNL500 FORK LIFT TRUCK FUSE
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$77.77/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # CNL500
North Coast Part # 153249

Features

  • All fuses are AC and DC rated
  • Expanded ampere ratings
  • Time-delay and general purpose types
  • Link is visible through window

Certifications

  • UL recognized components (All Products) File E60314

Specifications

  • Max Operating Temp: 80 °C
  • Max Storage Temp: 80 °C
  • Min Storage Temp: -25 °C
  • Ampere Rating: 500 A
  • Rated Voltage Dc Ul: 80 V
  • Ac Max I R Breaking Capacity I1: 2500 A
  • Country Of Origin: CN
  • Product Line: UL CNL Fuses
  • Body Insulating Material: GMG
  • Connection Terminal Material: Silver-Plated Copper
  • Connection Terminal Type: Blade
  • Mounting: Bolted

Overview

UPC 78200179079
Family Brand Name Ferraz Shawmut
Item Long Description Mersen forklift truck and battery isolator fuses are specially designed for the heavy duty loads associated with DC battery powered equipment such as forklift trucks, hand trucks, motorized work platforms, and other DC battery operated systems. Rugged construction and stud mounted bolt-in design assure a long life in adverse conditions for these fuses. This expanded line of forklift truck fuses can fulfill virtually all of your heavy duty circuit protection needs up to 125V AC or DC.
GTiN 00782001790790
Length 3.19 in
Width 0.63 in
Type Forklift Truck Fuses
Terminal Type Blade
Applications For Forklift Trucks, Battery Hand Trucks, Motorized Work Platforms, Battery Systems
Mounting Type Bolt-On
Height 0.63 in
Weight 0.04 lb
Pkg Qty 5
Insulation Material GMG
Amperage 500 Amp
Interrupt Rating 2.5 kA
Indicator Visual Indicator
Terminal Material Silver-Plated Copper
Rated Voltage DC 80 V
Voltage 80 VAC
Country of Origin China
Max Operating Temperature 80 C
