FERRAZ E300453 A070URD33TTI1250
$540.90/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # E300453
North Coast Part # 152377

Features

  • Multiple body sizes and terminals or blades combination
  • aR Class according to IEC 60269-4 and VDE 636-23
  • Very low I²t for improved semiconductor protection
  • Ultra fast acting
  • Current limiting
  • Superior cycling capability

Applications

  • Protection of inverters, motor drives, UPS systems and similar 690V or less equipments.

Approvals & Standards

  • IEC 60269-4 Compliance
  • UL/CSA Recognized E76491
  • CCC 1359.4

Specifications

  • Rated voltage AC UL: 700 V
  • Rated voltage AC IEC: 690 V
  • Ampere Rating: 1250 A
  • Speed/Characteristic: aR
  • Fuse Size: 33
  • Mounting: Bolted
  • Clearing I2t At Rated Voltage: 2053 kA²s
  • Melting I2t: 355 kA²s
  • AC Max I.R./Breaking Capacity: I1: 200 kA
  • Power Dissipation at Rated Current Value: 150 W
  • Design Details: Reinforced Terminal
  • Indication System: Yes
  • Indication System Type: Striker
  • Connection/Terminal Material: Silver-Plated Brass
  • Connection/Terminal Type: End Contact with Threaded Holes
  • Body/Insulating Material: Ceramic

Product Dimensions

  • Product Weight: 1.971 lb
  • Product Width: 2.87 in
  • Product Length: 1.99 in
  • Product Height: 3.09 in

Packaging Dimensions

  • Sell Pack Quantity: 3 EACH
  • Sell Pack Weight: 5.913 lb
  • Sell Pack Width: 3.39 in
  • Sell Pack Length: 9.72 in
  • Sell Pack Height: 3.7 in

Categories

Overview

UPC 78200124364
Family Brand Name Ferraz Shawmut
GTiN 03605340328653
Length 1.99 in
Width 2.87 in
Terminal Type End Contact With Threaded Holes
Mounting Type Bolted
Height 3.09 in
Weight 1.971 lb
Pkg Qty 3
Insulation Material Ceramic
Amperage 1250 Amp
Indicator Striker
Terminal Material Silver-Plated Brass
Rated Voltage AC 700 V
