FERRAZ GGU8 125V 8A 1-1/2X13/32 FUS
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 8 to 12 Days
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # GGU8
North Coast Part # 603507


  • Glass body on 1-15A makes status of fusible element clearly visible
  • Ceramic body on 20-30A allows use in higher temperature applications
  • Medium lag for protection of circuits up to 30A and 125VAC
  • Can be used with UltraSafeā„¢ fuse holders (1-30A)
  • 1 1/2" x 13/32" (10 mm x 38 mm) dimensions


  • General Purpose
  • 125VAC Circuits
  • Supplemental Protection

Approvals & Standards

  • UL Listed 1-15A
  • UL Recognized 20-30A


  • Rated voltage AC UL: 125 V
  • Ampere Rating: 8 A
  • Fuse Class: Midget
  • Speed/Characteristic: Fast-Acting
  • Mounting: Clip
  • AC Max I.R./Breaking Capacity: I1: 10 kA
  • Connection/Terminal Material: Tin-Plated Copper
  • Connection/Terminal Type: Ferrule
  • Body/Insulating Material: Ceramic

Product Dimensions

  • Product Weight: 0.012 lb
  • Product Diameter: 0.41 in
  • Product Length: 1.5 in

Packaging Dimensions

  • Sell Pack Quantity: 10 Each
  • Sell Pack Width: 0.88 in
  • Sell Pack Length: 1.62 in
  • Sell Pack Height: 2.12 in


Family Brand Name Ferraz Shawmut
Product UPC 78200176022
GTiN 00782001760229
Length 1-1/2 Inch
Type Supplemental Protection
Diameter 0.41 in
Terminal Type Ferrule
Applications General Purpose 125VAC Circuits Supplemental Protection
Mounting Type Clip
Weight 0.012 lb
Pkg Qty 10
Class M
Insulation Material Ceramic
TC Connection Ferrule
Amperage 8 Amp
Interrupt Rating 10 kA
Terminal Material Tin-Plated Copper
Rated Voltage AC 125 V
Fuse Class Midget
Voltage 125 VAC
