FERRAZ L300022 69URD31D11A0400
$310.78/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # L300022
North Coast Part # 494286

Features

  • Multiple body sizes and terminals or blades combination
  • aR Class according to IEC 60269-4 and VDE 636-23
  • Very low I²t for improved semiconductor protection
  • Ultra fast acting
  • Current limiting
  • Superior cycling capability

Applications

  • Protection of inverters, motor drives, UPS systems and similar 690V or less equipments.

Specifications

  • Sell Pack Height: 2.44 in
  • Product Weight: 0.913 lb
  • Product Length: 5.3 in
  • Mounting: Bolted
  • Clearing I2t At Rated Voltage: 110000 A²s
  • Product Width: 2.01 in
  • Ampere Rating: 400 A
  • AC Max I.R./Breaking Capacity: I1: 200 kA
  • Rated voltage AC IEC: 690 V
  • Product Height: 2.22 in
  • Power Dissipation at Rated Current Value: 68 W
  • Melting I2t: 19000 A²s
  • Indication System: Yes
  • Catalogue No.: PC31UD69V400D1A
  • Sell Pack Width: 5.59 in
  • Sell Pack Length: 6.54 in
  • Body/Insulating Material: Ceramic
  • Fuse Size: 31
  • Connection/Terminal Type: DIN Type Blades
  • Sell Pack Quantity: 3 EACH
  • Indication System Type: Striker
  • Speed/Characteristic: aR
  • Connection/Terminal Material: Silver-Plated Copper
  • Rated voltage AC UL: 700 V
  • Sell Pack Weight: 2.74 lb

Approvals & Standards

  • IEC 60269.4 Compliance
  • UL/CSA Recognized E76491
  • CCC GB 1539.4
  • Approvals & Standards

Categories

Overview

UPC 78200124010
Family Brand Name Ferraz Shawmut
GTiN 03605340322460
Length 5.3 in
Width 2.01 in
Terminal Type DIN Type Blades
Mounting Type Bolted
Height 2.22 in
Weight 0.913 lb
Pkg Qty 3
Insulation Material Ceramic
Amperage 400 Amp
Indicator Striker
Terminal Material Silver-Plated Copper
Rated Voltage AC 690 V
