Ferraz Shawmut RF15 15 Amp 250 Volt Fuse
Product image thumbnail 0
Product image thumbnail 1
$29.29/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # RF15
North Coast Part # 155139

Features

  • Knurled bushings for ease of disassembly
  • Precision die-cut renewal links renew quickly and give repeatable performance
  • Rugged construction for maximum service life

Product Details

  • I.R. AC: 10 kA
  • Standards: UL Listed to Standard 248-7, File E2137 CSA Certified to Standard C22.2, No. 248.7
  • ROHS Compliant: Consult Technical Services
  • AC Voltage: 250 VAC
  • Mounting: Clip
  • Body Material: FWGE
  • UL Certification: E3978 JDRX.E3978
  • Class: Class H
  • Connection Terminal Type: Ferrule Blade
  • Lead Free: Consult Technical Services
  • Materials Contact: Brass
  • Ampere Range: 2-600 A
  • CSA Certification: 1421-02 1421-02
  • CE conformity: Consult Technical Services
  • Speed / Characteristic: Fast-Acting
  • Body Style: Cylindrical
  • Applications: General purpose loads where short-circuit currents are 10, 000 amperes or less

Resources

Data Sheets

Overview

UPC 06893872007
Family Brand Name Ferraz Shawmut
GTiN 00068938720070
Voltage 250 Volt
Type Renewable, Fast Acting
Applications For General Purpose Loads Where Short-Circuit Currents are 10000 A or Less
Mounting Type Clip
Body Material FWGE
Class H
Contact Material Brass
TC Connection Ferrule
Amperage 2-600 Amp
Interrupt Rating 10 kA
Fuse Class Class H
