FERRAZ Y300240 A070URD33KI0630
$407.87/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Mersen
Mfg Catalog # Y300240
North Coast Part # 160081

Features

  • Multiple body sizes and terminals or blades combination
  • aR Class according to IEC 60269-4 and VDE 636-23
  • Very low I²t for improved semiconductor protection
  • Ultra fast acting
  • Current limiting
  • Superior cycling capability

Applications

  • Protection of inverters, motor drives, UPS systems and similar 690V or less equipments.

Specifications

  • Sell Pack Height: 3.54 in
  • Product Weight: 1.863 lb
  • Product Length: 5.28 in
  • Mounting: Bolted
  • Clearing I2t At Rated Voltage: 230 kA²s
  • Design Details: Standard Terminal
  • Product Width: 2.87 in
  • Ampere Rating: 630 A
  • AC Max I.R./Breaking Capacity: I1: 200 kA
  • Rated voltage AC IEC: 690 V
  • Product Height: 3.09 in
  • Power Dissipation at Rated Current Value: 120 W
  • Melting I2t: 40 kA²s
  • Indication System: Yes
  • Catalogue No.: A070UD33KI630
  • Sell Pack Width: 5.71 in
  • Sell Pack Length: 9.65 in
  • Body/Insulating Material: Ceramic
  • Fuse Size: 33
  • Connection/Terminal Type: Slotted Blades
  • Sell Pack Quantity: 3 EACH
  • Indication System Type: Striker
  • Speed/Characteristic: aR
  • Connection/Terminal Material: Silver-Plated Copper
  • Rated voltage AC UL: 700 V
  • Sell Pack Weight: 5.589 lb

Approvals & Standards

  • IEC 60269-4 Compliance
  • UL/CSA Recognized E76491
  • CCC 1359.4
  • Approvals & Standards

Categories

Overview

UPC 78200124392
Family Brand Name Ferraz Shawmut
GTiN 03605340325539
Length 5.28 in
Width 2.87 in
Terminal Type Slotted Blades
Mounting Type Bolted
Height 3.09 in
Weight 1.863 lb
Pkg Qty 3
Insulation Material Ceramic
Amperage 630 Amp
Indicator Striker
Terminal Material Silver-Plated Copper
Rated Voltage AC 690 V
