MILB UAP6095-O-NES GENERAL ENCLOSUR
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$7,984.46/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Milbank
Mfg Catalog # UAP6095-O-NES
North Coast Part # 1332808

Specifications

  • Brand Name: Milbank
  • Type: Terminal Box
  • Special Features: 4000 Ampere; Three Phase Four Wire; Penta Bolt; 10,000 Short Circuit Current Rating
  • Application: Terminate Conductors
  • Standard: UL Listed
  • Number Of Outlet: 0
  • Material: Aluminum
  • Size: 32.375 In x 16 In x 43 In
  • Color: ANSI 61 Gray
  • Construction: Welded
  • Cable Entry: No Knockouts
  • Mounting: Pad Mount or Wall Mount
  • NEMA Rating: Type 3R
  • Hinge Type: Lift Off Hinges
  • Top: Plain Top
  • Door: Hinged Cover
  • Latch: Padlocking Handle with 3 Point Latch Assembly
  • Support: Body Stiffeners
  • Height: 43 IN
  • Length: 16 IN
  • Width: 32.375 IN
  • UNSPSC Number: 39121324
  • Product Family Code: GEEN
  • Product Family Disclaimer: Please consult serving utility for their requirements prior to ordering or installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must be installed by a licensed electrician and must comply with all national and local codes, laws and regulations. Milbank reserves the right to make changes in specifications and features shown without notice or obligation.

Overview

UPC 78457270392
Item Long Description ALUM PAINTED SHELL 22 POS PER PHASE BAR 500 KCMIL PENTA BOLT
GTiN 00784572703926
Length 16 in
Width 32.375 in
Size 32.375 In x 16 In x 43 In
Color Gray
Type Terminal Box
Material Aluminum
Applications Terminate Conductors
Mounting Type Pad Mount,Wall Mount
Height 43 in
Standard UL Listed
Family Brand Name Milbank
Construction Welded
NEMA 3R
Door Type Hinged Cover
Number of Outlets 0
Cable Entry No Knockouts
Latch Type Padlocking Handle With 3 Point Latch Assembly
