Milwaukee 48-89-9203 #3 1/4" - 3/4" by 1/16" Step Drill Bit
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Already a Customer? Log in to view your pricing
Manufacturer Milwaukee Tool
Mfg Catalog # 48-89-9203
North Coast Part # 1165462


  • JAM-FREE Performance: Dual-flute design provides greater speed and control
  • Up to 2X faster: optimized for cordless drills in high speed
  • Rapid Strikeā„¢ tip: creates fast, accurate starts and generates less heat
  • Up to 4X longer bit life: optimized geometry with black oxide coating to cut faster and produce less heat
  • Up to 50% more holes per battery charge for more productivity
  • Laser-engraved reference marks easily stop on any hole size
  • 3-Flat secure-grip shanks reduce bit slippage in the chuck
  • Made in the USA


  • Bit Diameter: Varies
  • Bit Material: Black Oxide
  • Bit Type: Step
  • Length (in): 6.0
  • Package Contents: 1 Bit
  • Shank Diameter (in): 0.375
  • Drilling Depth (in): 6.0
  • Minimum Chuck Size Required: 1/4 in
  • Flute Length (in): 0.5
  • Single / Double Ended: Single
  • Recommended Safety Equipment: Safety Glasses


UPC 04524230765
Item Long Description Milwaukee step drill bits with jam-free performance feature a dual-flute design delivering up to 2X faster hole times, up to 4X longer life and up to 50% more holes per battery charge than competitors. Ideal for drilling small and large-diameter holes in steel and plastic, these bits are optimized for cordless drills in high speed. The Rapid Strike tip allows for a fast and accurate start that generates less heat, resulting in longer bit tip life. Black oxide coating also enhances durability, hole quality and bit life. For user convenience and accuracy, each bit has laser-engraved reference marks you can see while drilling. The 3-flat Secure-Grip shank ensures a solid connection with the drill chuck. The #3 step drill bit has 9 hole sizes in 1/16 in. increments ranging from 1/4 in. to 3/4 in. jam-free performance in high speed with most professional 18 Volt cordless drills with lithium-ion battery technology.
GTiN 00045242307654
Finish Black Oxide
Size #3
Material High Speed Steel
Shank Size 3/8 in
Shank Type 3-Flat
Pkg Qty 1 Pack
Coating Black Oxide
Family Brand Name Milwaukee
Number of Flutes 2
Number of Steps 9
Overall Length 3 in
Length 6.0 in
Shank Diameter 0.375 in
Flute Length 0.5 in
Drilling Depth 6.0 in
