NUTONE HD80LNT Fan/Light,Nutone,HEA
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$192.06/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Nutone
Mfg Catalog # HD80LNT
North Coast Part # 491642

Overview

These products are named Heavy Duty for good reason. They're built tough to last in those punishing applications that are just too much for typical residential products. And a broad spectrum of AMCA and HVI certified performance ratings means there's an HD Series Fan or Fan/Light that's just right for your next light-commercial or institutional application.

  • 80 CFM, 2.5 Sones quickly reduces humidity and odors to prevent or eliminate fogged mirrors and manage moisture in bathrooms up to 75 square feet, so your vision will be clear and your surroundings will always be comfortable
  • A 2.5 Sone rating provides quality ventilation at moderate sound levels
  • Matte white polymeric lens and fan grille blends nicely with your ceiling and any decor (11-1/8" x 10-5/8")
  • Up to 100-watt incandescent bulb (not included) provides ample lighting so you can complete your tasks
  • UL Listed for use over tub or shower with a GFCI circuit; that means you can optimize ventilation effectiveness by locating your fan exactly where you need it the most
  • Totally enclosed motor designed for continuous operation and minimal maintenance
  • Rugged metal fan grille for added durability means breakage will not be a concern
  • AMCA licensed for both air and sound to meet many light commercial requirements

Specifications

  • Rated Watts: 49
  • Project Pack: No
  • Globe Glass Color: N/A
  • Grille Length: 10-5/8"
  • Baths up to () Sq Ft: 75
  • Heater Wattage: N/A
  • Watts @ 0.1": 49
  • CFM @ 0.10": 80
  • CSA: No
  • ENERGY STARĀ® Most Efficient 2015: No
  • Sones 6" to 4" reducer: N/A
  • CFM @ 0.25": 65
  • Ceiling Installation: Yes
  • Housing Width: 8-1/4"
  • Housing Height: 5-3/4"
  • Duct Size: 4"
  • Rated Sones: 2.5
  • Grille Diameter: N/A
  • Grille Width: 11-1/8"
  • Motion Sensing: No
  • Rated Amps: 1.5
  • cUL Listed: Yes
  • UL Listed for use over bathtubs or showers when connected to a GFCI circuit: Yes
  • Humidity Sensing: No
  • Light Bulbs Included: No
  • Watts @ 0.1" (Max CFM): 49
  • Light Bulb Wattage: 100
  • Watts @ 0.25": 48
  • Minimum construction space required: 2" x 6"
  • Warranty: 1 Year
  • Housing Dimension LxWxH: 8" x 8-1/4" x 5-3/4"
  • Motor engineered for continuous operation: No
  • Nightlight: No
  • Rated Sones - Vertical: N/A
  • Housing Length: 8"
  • ENERGY STARĀ® qualified: Yes
  • Product Weight (Pounds): 5.4
  • Duct Direction: Horizontal
  • Color: White
  • Grille Finish: White Polymeric
  • HVI Certified: Yes
  • Light Bulb Quantity: 1
  • Wall Installation: No
  • Lighting Type: Incandescent

Video Links

Resources

Overview

UPC 78489195109
Item Long Description Heavy Duty Fan/Light. 80 CFM, 2.5 Sones. 100-watt lamp capacity (bulb not included). Type IC (Insulation Contact)
GTiN 00784891951091
Warranty Length 1 yr
Color White
Weight 5.4 lb
Wattage 100 Watt
Family Brand Name Nutone
Rated Sones 2.5
Light Type Incandescent
Amperage 1.5 Amp
Grille Width 11-1/8 in
Housing Length 8 in
Duct Size 4 in
Grille Length 10-5/8 in
Housing Height 5-3/4 in
Housing Width 8-1/4 in
Nightlight No
