Panduit ABMM-AT-D0 0.75 x 0.75 Inch Adhesive High Temperature Cable Tie Mount

Specifications

• Product Segment: IEI
• Product Type: Cable Tie Mount
• Application: Cable Tie Entry from All Four Sides, Used with Miniature, and Intermediate Cables Ties
• Color: Black
• Environment: Outdoor
• Material: Weather Resistant ABS
• Maximum Compatible Panel Thickness (In.): 0.04
• Maximum Compatible Panel Thickness (mm): 1
• Maximum Operating Temperature (°C): 82
• Maximum Operating Temperature (°F): 179.6
• Minimum Operating Temperature (°C): -29
• Minimum Operating Temperature (°F): -20.2
• Mount Method: Acrylic Adhesive Tape
• Overall Height (mm): 4.6
• Overall Height (In.): 0.18
• Overall Length (mm): 19
• Overall Length (In.): 0.75
• Overall Width (mm): 19
• Overall Width (In.): 0.75
• Resistance Properties: UV Resistant
• Standards Met: CE Compliant, UL Recognized: E136577, RoHS Compliant
• Static Load Capacity (kg): 0.1
• Static Load Capacity (lb): 0.3

Packaging Details

• UPC: 07498358493
• GTIN Package: 00074983584932
• Standard Package Volume Ft3: 0.0528
• Standard Package Weight Pounds: 0.7000
• Std Package Height In: 2.4
• Std Package Height MM: 60.96
• Std Package Length In: 9
• Std Package Length MM: 228.6
• Std Package Width In: 7.3
• Std Package Width MM: 185.42
• Std. Pkg. UOM: Piece
• UOM EA PK: PK
• Std. Pkg. Qty.: 500
• GTIN Carton: 50074983584937
• Standard Carton Volume Ft3: 0.0528
• Standard Carton Weight Pounds: 7.0000
• Std Carton Height In: 9
• Std Carton Height MM: 228.6
• Std Carton Length In: 11.05
• Std Carton Length MM: 228.6
• Std Carton Width In: 9.1
• Std Carton Width MM: 231.14
• Std Ctn Qty: 5000
• Min. Order UOM: Piece
• Country of Origin 2Digit: US
• RoHS Compliant: Compliant
• EAN: 00074983584932
• REACH Status: False
• California Pro65 Cancer: No
• Buy American Compliant: Y
• ARRA Compliant: Y
• Mercury Content Indicator: No
• Hazardous Material Flag: N
• Min Order Qty: 500
