PAN BM1M-C MrkrTie,Wrap,4.2L,M,Nyl,

Specifications

• UNSPSC: 39121703
• Product Segment: IEI
• Sub Brand: Dome-Top®
• Product Type: Cable Tie
• Color: Natural
• Environment: Indoor
• For use with: Bundles
• Marker Type: Wrap
• Material: Nylon 6.6
• Maximum Bundle Diameter (In.): 0.9
• Maximum Bundle Diameter (mm): 23
• Maximum Installation Temperature (°C): 0
• Maximum Installation Temperature (°F): 32
• Maximum Operating Temperature (°F): 185
• Maximum Operating Temperature (°C): 85
• Minimum Bundle Diameter (mm): 4.8
• Minimum Bundle Diameter (In.): 0.18
• Minimum Installation Temperature (°C): -20
• Minimum Installation Temperature (°F): -4
• Minimum Loop Tensile Strength (lb): 18
• Minimum Loop Tensile Strength (N): 80
• Minimum Operating Temperature (°C): -60
• Minimum Operating Temperature (°F): -70
• Overall Length (mm): 107
• Overall Length (In.): 4.2
• Body Width (mm): 2.4
• Body Width (In.): 0.095
• Body Thickness (In.): 0.046
• Body Thickness (mm): 1.2
• Resistance Properties: NA
• Standards Met: UL 62275 Compliant (Type 1, 11),CE Compliant,RoHS Compliant
• Application: General

Packaging Details

• UPC: 07498373850
• GTIN Package: 00074983738502
• Standard Package Volume Ft3: 0.0236
• Standard Package Weight Pounds: 0.1700
• Std Package Height In: 1.05
• Std Package Height MM: 26.67
• Std Package Length In: 6.55
• Std Package Length MM: 166.37
• Std Package Width In: 5.7
• Std Package Width MM: 144.78
• Std. Pkg. UOM: Piece
• UOM EA PK: PK
• Std. Pkg. Qty.: 100
• GTIN Carton: 50074983738507
• Standard Carton Volume Ft3: 0.0236
• Standard Carton Weight Pounds: 1.7000
• Std Carton Height In: 5.95
• Std Carton Height MM: 151.13
• Std Carton Length In: 10
• Std Carton Length MM: 166.37
• Std Carton Width In: 6.85
• Std Carton Width MM: 173.99
• Std Ctn Qty: 1000
• Min. Order UOM: Piece
• Country of Origin 2Digit: CR
• RoHS Compliant: Compliant
• EAN: 00074983738502
• REACH Status: False
• California Pro65 Cancer: No
• Buy American Compliant: Y
• ARRA Compliant: Y
• Mercury Content Indicator: No
• Lead Content Indicator: N
• Restricted Use of Hazardous Substances: N
• Hazardous Material Flag: N
• Min Order Qty: 100
