PAN CD-920-500 Panduit CD-920-500 C
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$214.28/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # CD-920-500
North Coast Part # 552082

Specifications

  • Product Segment: IEI
  • Metric Class 2r Conductor Size for Copper Lugs, Splices(mm²): 240
  • Copper Conductor Size (kcmil): 500
  • Aluminum Conductor Size (kcmil): 350
  • Panduit Die Index Number: P87
  • Color Code: Brown
  • Flex Conductor Size (kcmil): 444
  • For Use With: Crimp die for use with Panduit CT-920, CT-2920, CT-930, CT-2930/L, CT-2930/LE, CT-2931 and CT-2931/E crimp tools and CT-930/CH crimp head, can also be used with Panduit CT-2940/L and CT-2940/LE crimp tools and CT-940CH crimp head with CD-940-DA die adapter sold separately.
  • Connection Type: Crimp
  • Sub Brand: Pan-Lug™
  • Application: Crimp dies for Panduit Power Connectors and Splices.
  • Crimp Profile: Circumferential
  • Base Material: Steel
  • Finish/Coating: Black Oxide
  • Product Type: CD-920 Crimp Dies

Packaging Details

  • UPC: 07498391451
  • GTIN Package: 00074983914517
  • Standard Package Volume Ft3: 0.0087
  • Standard Package Weight Pounds: 0.6000
  • Std Package Height In: 1
  • Std Package Height MM: 25.4
  • Std Package Length In: 5.4
  • Std Package Length MM: 137.16
  • Std Package Width In: 3.45
  • Std Package Width MM: 87.63
  • Std. Pkg. UOM: Piece
  • UOM EA PK: EA
  • Std. Pkg. Qty.: 1
  • Standard Carton Volume Ft3: 0.0087
  • Standard Carton Weight Pounds: 0.0000
  • Std Carton Length MM: 137.16
  • Std Ctn Qty: 0
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: US
  • RoHS Compliant: RoHS directive is not applicable
  • EAN: 00074983914517
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Hazardous Material Flag: N
  • Min Order Qty: 1
  • Pallet Quantity: 0
  • Pallet Volume: 0.000000
  • Pallet Weight: 0.0000

Overview

UPC 07498391451
Item Long Description The CD-920-500 Crimp Die provides circumferential crimp results in terminations with premium electrical and mechanical performance with Panduit copper compression lugs and splices. Crimping dies and connectors are color-coded for easy matching while the part number is permanently marked on the crimping die for easy identification. Crimp die designed for use with Panduit CT-920, CT-920CH, CT-930, CT-930CH, and CT-2920 tools.
GTiN 00074983914517
Size 500 kcmil
Type CD-920 Crimp Dies
Applications Cable compression lugs and connectors
Country of Origin US
Pkg Qty 1
Family Brand Name Panduit
Sub Brand Crimping Dies
CA Prop65 Warning No
