PAN FODPZ48Y Fiber Ind Dist Cable O
$22,170.35/m (1000 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # FODPZ48Y
North Coast Part # 1684647

Specifications

  • Product Segment: EDI-ENT
  • UNSPSC: 26121607
  • Note: Intended for use in fixed installations which are outside the scope of RoHS
  • Cable Construction: Distribution
  • Environment: Indoor
  • Fiber Type: OM4
  • Number of Fibers: 48
  • Fiber Diameter (µm): 50
  • Outer Diameter (In.): 0.66
  • Outer Diameter (mm): 16.7
  • Bend Radius (In.): 6.6
  • Bend Radius (mm): 167.6
  • Maximum Operating Temperature (°F): 158
  • Maximum Operating Temperature (°C): 70
  • Minimum Operating Temperature (°C): -20
  • Minimum Operating Temperature (°F): -4
  • Maximum Installation Temperature (°F): 140
  • Maximum Installation Temperature (°C): 60
  • Minimum Installation Temperature (°F): 32
  • Data Transfer Rate (Gb/s): 10
  • Maximum Installation Tension (lb): 99
  • Maximum Installation Tension (N): 440
  • Resistance Properties: Flame-Resistant
  • Cable Color: Black
  • Flammability Rating: Plenum
  • Product Type: Distribution Cable
  • Application: For Indoor use in Intra-Building Backbone and Horizontal Installations.
  • Connection Type: NA
  • Standards Met: RoHS directive is not applicable; UL-1666; NFPA 262; ANSI/ICEA S-83-596; CSA 22.2; Telcordia GR-409; TIA-492AAAB; TIA-492AAAC; TIA-492AAAD; IEC 60793-2-10
  • Sub Brand: Opti-Core

Packaging Details

  • UPC: 07498320658
  • GTIN Package: 00074983206582
  • Standard Package Volume Ft3: 5.8333
  • Standard Package Weight Pounds: 0.1219
  • Std Package Height In: 12
  • Std Package Height MM: 304.8
  • Std Package Length In: 48
  • Std Package Length MM: 1219.2
  • Std Package Width In: 17.5
  • Std Package Width MM: 444.5
  • Std. Pkg. UOM: Foot
  • UOM EA PK: EA
  • Std. Pkg. Qty.: 1
  • Standard Carton Volume Ft3: 5.8333
  • Standard Carton Weight Pounds: 0.0000
  • Std Carton Length MM: 1219.2
  • Std Ctn Qty: 0
  • Min. Order UOM: Foot
  • Country of Origin 2Digit: US
  • RoHS Compliant: RoHS directive is not applicable
  • EAN: 00074983206582
  • NLD HS Code: 8544700000000000000000
  • ECCN Commodity Code: EAR99
  • REACH Status: False
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Hazardous Material Flag: N
  • Min Order Qty: 1,640

Overview

UPC 07498320658
GTiN 00074983206582
Color Aqua
Type Distribution Cable
Applications Inside
Country of Origin US
Fiber Type OM4
Pkg Qty 1
Cable Color Black
Family Brand Name Panduit
Carton Qty 0
Max Operating Temperature 158 degrees F
Fiber Cable Size OM4 10 GbE 50/125m
Min Operating Temperature -4 degrees F
Jacket Material PVC
Tensile Strength 660 N
Bend Radius 310 mm
Number of Fibers 48
Sub Brand Opti-Core
