PAN FXTRP7N7NANF040 OM3,12-Fiber,PL
Product image thumbnail 0
Product image thumbnail 1
$537.26/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # FXTRP7N7NANF040
North Coast Part # 1893301

Specifications

  • UNSPSC: 26121650
  • Product Segment: EDI-DC
  • Fiber Type: OM3
  • Number of Fibers: 12
  • Connector 1 Type: PanMPO Female
  • Connector 2 Type: PanMPO Female
  • Maximum Connector Insertion Loss (dB): 0.5
  • Flammability Rating: Plenum
  • Minimum Connector Return Loss (dB): 26
  • Overall Length (m): 12.19
  • Overall Length (ft.): 40
  • Fiber Diameter (µm): 50
  • Outer Diameter (mm): 3
  • Outer Diameter (In.): 0.11811
  • Maximum Operating Temperature (°F): 140
  • Maximum Operating Temperature (°C): 60
  • Minimum Operating Temperature (°C): -10
  • Minimum Operating Temperature (°F): 14
  • Maximum Installation Temperature (°F): 104
  • Maximum Installation Temperature (°C): 40
  • Minimum Installation Temperature (°F): 32
  • Resistance Properties: Flame-Resistant
  • Cable Color: Aqua
  • Environment: Indoor
  • Standards Met: Meets or exceeds TIA/EIA-568-C.3, TIA-604-5 (FOCIS-5), TIA/EIA-568-C.1, RoHS Compliant
  • Application: Interconnect cables are small in diameter, extremely flexible and intended for shorter cable runs. These small cables minimize waste, optimize cable management, speed deployment, and improve flexibility and manageability.
  • Product Type: Interconnect Cable Assembly
  • Boot Color: Black
  • Sub Brand: QuickNet

Packaging Details

  • UPC: 07498357038
  • GTIN Package: 00074983570386
  • Standard Package Volume Ft3: 0.0513
  • Standard Package Weight Pounds: 0.4300
  • Std Package Height In: 1.5
  • Std Package Height MM: 38.1
  • Std Package Length In: 14
  • Std Package Length MM: 355.6
  • Std Package Width In: 17
  • Std Package Width MM: 431.8
  • Std. Pkg. UOM: Piece
  • UOM EA PK: EA
  • Std. Pkg. Qty.: 1
  • GTIN Carton: 50074983570381
  • Standard Carton Volume Ft3: 0.0513
  • Standard Carton Weight Pounds: 4.3000
  • Std Carton Height In: 5
  • Std Carton Height MM: 127
  • Std Carton Length In: 12.8
  • Std Carton Length MM: 355.6
  • Std Carton Width In: 12.8
  • Std Carton Width MM: 325.12
  • Std Ctn Qty: 10
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: CR
  • RoHS Compliant: Compliant
  • EAN: 00074983570386
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: N
  • ARRA Compliant: N
  • Mercury Content Indicator: No
  • Hazardous Material Flag: N
  • Min Order Qty: 1
  • Pallet Quantity: 810
  • Pallet Volume: 41.589844
  • Pallet Weight: 348.3000

Overview

UPC 07498357038
Item Long Description OM3 12-fiber, interconnect, plenum, PanMPO Female To PanMPO Female, method A, Std. IL, no pulling eye - 40ft.
GTiN 00074983570386
Length 12.2 m
Color Aqua
Type OM3, 12-Fiber
Material Plenum
Applications For Indoor use
Country of Origin Costa Rica
Fiber Type OM3
Pkg Qty 1
Family Brand Name Panduit
Overall Length 40 ft
Number of Fibers 12
Sub Brand QuickNet
CA Prop65 Warning No
Connector Type PanMPO Female
Cable Length 40 ft
Fiber Cable Size 50/125 m
Cable Color Aqua
Max Operating Temperature 140 degrees F
Min Operating Temperature 14 degrees F
Boot Color Black
UNSPSC 26121650
