PAN HSECFR1.5-5Y HeatShrinkThickAdh
Product image thumbnail 0
Product image thumbnail 1
$16.90/ea
Usually ships within 6 to 10 Days
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # HSECFR1.5-5Y
North Coast Part # 598851

Specifications

  • Material: Flame retardant cross-linked polyolefin with adhesive
  • Sub Brand: Heat Shrink End Cap
  • Note: replaces HSECFR1.5-5
  • Flammability Rating: V-0
  • Brand Name: Panduit
  • Order Multiple Quantity Each: 1
  • Order Min Qty Each: 1
  • Color: Black
  • Type: WET-SHRINK Heat Shrink End Cap Flame Retardant Adhesive Lined

Packaging Details

  • Std Carton Height MM: 248.92
  • Std Package Width: 8
  • Std Package Width MM: 203.2
  • GTIN Package: 00074983107063
  • Std Package Height: 1.5
  • Std Carton Width MM: 231.14
  • UNSPSC Package Description: PACKAGE
  • Sell Pkg Qty 1: 1
  • Std Carton Width: 9.1
  • Std Package Height MM: 38.1
  • Std Carton Height: 9.8
  • Std Carton Length MM: 368.3
  • GTIN Carton: 50074983107068
  • UNSPSC Carton Description: CARTON
  • Std Carton Length: 14.5
  • Std Package Length MM: 279.4
  • Std Package Length: 11
  • UNSPSC Piece UOM: EA
  • Ship Pack Packaging Description: CTN
  • UNSPSC Piece Desription: EACH
  • Sell Pack Packaging Description: CTN
  • UNSPSC Package UOM: PK
  • UNSPSC Carton UOM: CT
  • Part Number Full UPC: 7498310706
  • Minimum Order Quantity: 5
  • Standard Package Quantity: 5
  • Stanard Carton Quantity: 50
  • Standard Package Weight: 0.5
  • Standard Carton Weight: 5

Certifications & Approvals

  • Ozone Depleting Compounds: N
  • CE Marking: No
  • ARRA Compliant: Y
  • MSDS Indicator: N
  • FIFRA Indicator: N
  • CE Compliant: No
  • CSA Certified: No
  • RoHS Compliancy Status: Compliant
  • UL Recognized: Yes
  • ECCN Commodity Code: EAR99
  • Buy American Compliant: Y

Additional Specifications

  • UNSPSC: 39121723
  • Min. Expanded I.D. (In.): 1.50
  • Max. Recovered I.D. (In.): 0.47
  • Product Group Assignment: Abrasion Protection
  • Gross Volume UOM: CU
  • Copper Conductor Size Range: 2/0 AWG -350 MCM
  • Max. Recovered I.D. (mm): 11.9
  • Master Pack Quantity: 10
  • Unit Volume: .0141016
  • Unit Weight: .1
  • UOM EA Pk: PK
  • Country of Origin Description: Canada
  • Nominal Recovered Wall Thickness (mm): 4.1
  • Cap Length (In.): 3.50
  • Master Pack Packaging Description: BAG
  • Country of Origin 2Digit: CA
  • Model (Design): End caps
  • Min. Expanded I.D. (mm): 38.1
  • Shelf Life: 3650
  • NMFC Rate: 70
  • Temperature Range: -67°F - 239°F (-55°C - 110°C)
  • Hazardous Material Flag: N
  • Shrink Ratio: 3:1
  • Cap Length (mm): 88.9
  • Lowest Level UOM: EA
  • Conductor Size Range (mm²): 120 - 240
  • Nominal Recovered Wall Thickness (In.): 0.16

Documents

Catalog Cut Sheets

Part Drawings

Selection Guides

Overview

UPC 07498310706
GTiN 00074983107063
Color Black
Type Flame Retardant
Thickness 4.1 mm
Material Flame Retardant Cross-Linked Polyolefin With Adhesive
Shrink Ratio 3:1
Family Brand Name Panduit
Buy American Compliant Yes
CE Compliant No
ARRA Compliant Yes
Hazmat Flag No
Outside Diameter 38.1 mm
Inside Diameter 11.9 mm
Country of Origin CA
Pkg Qty 5
Carton Qty 50
Max Operating Temperature 230 degrees F
Overall Length 4.87 in
Min Operating Temperature -67 degrees F
UNSPSC 39121723
Temperature Rating -67 to 239 F
Wall Thickness 4.1 mm
