PAN LCAS1-12-E CuLug,#1AWG,Short,1/
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$894.28/c (100 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # LCAS1-12-E
North Coast Part # 680734

Specifications

  • Length In (mm): 1.94 (49.3)
  • Length (In.): 1.94
  • Brand Name: Panduit
  • Length (mm): 49.3
  • Order Min Qty Each: 1
  • Sub Brand: Type LCAS
  • Order Multiple Quantity Each: 1
  • Material: Tin-Plated Copper

Documents

Articles

Catalog Cut Sheets

Part Drawings

Selection Guides

System Bundle

Packaging Details

  • UNSPSC Package UOM: PK
  • Std Package Height MM: 86.36
  • Sell Pack Packaging Description: BOX
  • Std Package Length: 3.9
  • Ship Pack Packaging Description: BOX
  • Sell Pkg Qty 1: 1
  • UNSPSC Package Description: PACKAGE
  • Std Package Width MM: 60.96
  • Std Package Height: 3.4
  • UNSPSC Piece UOM: EA
  • GTIN Package: 00074983225361
  • Std Package Length MM: 99.06
  • UNSPSC Piece Desription: EACH
  • Std Package Width: 2.4
  • Part Number Full UPC: 7498322536
  • Minimum Order Quantity: 1
  • Standard Package Quantity: 20
  • Stanard Carton Quantity: 0
  • Standard Package Weight: 0.84599999999999997
  • Standard Carton Weight: 0

Certifications & Approvals

  • ECCN Commodity Code: EAR99
  • CE Marking: No
  • Tested by Telcordia-Meets NEBS Level 3: Yes
  • CE Compliant: No
  • Buy American Compliant: Y
  • MSDS Indicator: N
  • UL Listed: 486A-486B File #E52164
  • CSA Certified: C22.2 No. 65-13
  • UL and CSA Temperature Rating: 90°
  • UL and CSA Voltage Rating: 35kV
  • American Bureau Shipping Approved: Yes
  • Ozone Depleting Compounds: N
  • Tin-Plating Meets ASTM B545-97, Class C: 320µ in (8µ m)
  • ARRA Compliant: Y
  • RoHS Compliancy Status: Compliant

Additional Specifications

  • Hazardous Material Flag: N
  • Tongue Type: Standard
  • Gross Volume UOM: CU
  • Panduit Color Code: Green
  • Wire Strip Length (mm): 17.5
  • Unit Volume: .0005208
  • Stud Hole Size In. (mm): 1/2 (12.7)
  • Clearance: 0.60
  • Country of Origin 2Digit: MX
  • Barrel Length In. (mm): 0.59 (15.0)
  • Copper Conductor Size: #1 AWG
  • UOM EA Pk: PK
  • Tongue Thickness: 0.09
  • Barrel Length (mm): 15.0
  • Lowest Level UOM: EA
  • T&B Die Index No.: 37
  • Part Number Series: LCAS
  • Panduit Die Index No.: P37
  • Country of Origin Description: Mexico
  • Stud Hole Size (mm): 12.7
  • Tongue Thickness (mm): 2.3
  • Tongue Width In. (mm): 0.75 (19.1)
  • Tongue Width (mm): 19.1
  • Burndy Die Index No.: 11
  • Master Pack Packaging Description: BOX
  • Code Conductor Size: #1 AWG Code
  • Tongue Angle: Straight
  • NMFC Rate: 70
  • Corona Relief Taper: No
  • Conductor Material: Copper
  • Barrel Style: Standard
  • Barrel Type: Short Barrel Length with Inspection Window
  • Master Pack Quantity: 1
  • Product Group Assignment: Power Connectors
  • Technical Information: Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V
  • UNSPSC: 39121405
  • Angle: Straight
  • Wire Strip Length In. (mm): 11/16 (17.5)
  • Barrel Length (In.): 0.59
  • Tongue Width (In.): 0.75
  • Wire Strip Length (In.): 11/16
  • Conductor Size: #1 AWG Code
  • Stud Hole Size (In.): 1/2
  • Unit Weight: .0423
  • Tongue Thickness In. (mm): 0.09 (2.3)

Overview

UPC 07498322536
Item Long Description One-hole, short barrel with window lug, #1 AWG wire, 1/2" stud hole.
GTiN 00074983225361
Length 1.94 in
Size #1 AWG Code
Color Green
Type Tin-Plated Copper Compression Connectors - Lugs
Barrel Type Short Barrel Length with Inspection Window
Material Tin Plated Copper
Stud Size 42,767 IN
Number of Holes 1 Hole
Country of Origin Mexico
Angle Straight
Tongue Type Standard
Tongue Width 3/4 in
Pkg Qty 20
Family Brand Name Panduit
Conductor Material Copper
Buy American Compliant Yes
CE Compliant No
ARRA Compliant Yes
Hazmat Flag No
Overall Length 1.94 in
Barrel Length .59 in
Tongue Thickness .09 in
Color Coding Green
Sub Brand Pan-Lug
CA Prop65 Warning No
Voltage 35,000 Volt
UNSPSC 39121405
Product Type Power Connectors
Stud Hole Size 1/2 in
