PAN LCAX4-38-L CuLug,#4AWG,3/8StudP
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$399.95/c (100 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # LCAX4-38-L
North Coast Part # 666004

Specifications

  • Product Segment: IEI
  • UNSPSC: 39121405
  • Product Type: Tin-Plated Copper Compression Connectors - Lugs
  • Sub Brand: Pan-Lug
  • Stud Hole Size (In.): 42.95
  • Stud Hole Size (mm): 9.5
  • Barrel Type: Standard Barrel Length with Inspection Window
  • Barrel Length (In.): 0.53
  • Barrel Length (mm): 13.5
  • Tongue Type: Standard Tongue Width
  • Tongue Width (In.): 0.62
  • Tongue Width (mm): 15.7
  • Tongue Angle: Straight
  • Tongue Thickness (In.): 0.07
  • Tongue Thickness (mm): 1.8
  • Overall Length (In.): 1.57
  • Overall Length (mm): 39.9
  • Color Code: Gray
  • Panduit Die Index Number: P29
  • Burndy Die Index Number: 8
  • Wire Strip Length (mm): 15.8
  • Wire Strip Length (In.): 42,952

Packaging Details

  • UPC: 07498343418
  • GTIN Package: 00074983434183
  • Standard Package Volume Ft3: 0.0328
  • Standard Package Weight Pounds: 1.2700
  • Std Package Height In: 3.4
  • Std Package Height MM: 86.36
  • Std Package Length In: 4.75
  • Std Package Length MM: 120.65
  • Std Package Width In: 3.45
  • Std Package Width MM: 87.63
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 50
  • Standard Carton Volume Ft3: 0.0328
  • Standard Carton Weight Pounds: 0.0000
  • Std Carton Length MM: 120.65
  • Std Ctn Qty: 0
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: MX
  • RoHS Compliant: Compliant
  • EAN: 00074983434183
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Lead Content Indicator: N
  • Restricted Use of Hazardous Substances: N
  • Hazardous Material Flag: N
  • Min Order Qty: 1

Overview

UPC 07498343418
Item Long Description One-hole, flex lug, #4 AWG wire, 3/8 stud hole.
GTiN 00074983434183
Size #4 AWG Class B, C, G, H, I, K, M and #5, #4, #3 AWG DLO
Color Gray
Type Tin-Plated Copper Compression Connectors - Lugs
Barrel Type Standard Barrel Length With Inspection Window
Material Tin-Plated Copper
Stud Size 0.375 in
Number of Holes 1 Hole
Country of Origin MX
Angle Straight
Pkg Qty 50
Family Brand Name Panduit
Overall Length 1.57 in
Barrel Length 0.53 in
Color Coding Gray
Sub Brand Copper Compression Lug - Flex
CA Prop65 Warning No
Voltage 35,000 Volt
UNSPSC 39121405
