PAN LCCX4/0-12-X Panduit LCCX4/0-12
Product image thumbnail 0
Product image thumbnail 1
$2,526.48/c (100 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # LCCX4/0-12-X
North Coast Part # 602526

Specifications

  • Product Segment: IEI
  • Outer Diameter (In.): 0.71
  • Outer Diameter (mm): 18.03
  • Inside Diameter (mm): 14.47
  • Inside Diameter (In.): 0.57
  • Product Type: Tin-Plated Copper Compression Connectors - Lugs
  • Lug Type: 2 Stud Hole Lug
  • Base Material: Copper
  • Sub Brand: Pan-Lug™
  • Copper Code Conductor Size (AWG): 4/0
  • DLO Copper Flex Conductor Size (AWG): 4/0
  • Stud Hole Size (mm): 12.7
  • Stud Hole Size (In.): 1/2
  • Stud Hole Spacing (In.): 1.75
  • Stud Hole Spacing (mm): 44.5
  • Barrel Type: Long Barrel with Inspection Window
  • Barrel Length (mm): 56.9
  • Barrel Length (In.): 2.24
  • Tongue Type: Standard
  • Tongue Width (mm): 30.2
  • Tongue Width (In.): 1.19
  • Tongue Angle: Straight
  • Tongue Thickness (In.): 0.16
  • Tongue Thickness (mm): 4.1
  • Overall Length (mm): 145.5
  • Overall Length (In.): 5.73
  • Finish/Coating: Tin-Plated
  • Standards Met: C22.2 No. 65-13, 486A-486B File #E52164
  • UL Temperature Rating (°C): 90
  • Maximum Voltage (kV): 35
  • Color Code: Purple
  • Panduit Die Index Number: P54
  • Burndy Die Index Number: 15
  • T & B Die Index Number: 15
  • Wire Strip Length (In.): 1-5/8
  • Wire Strip Length (mm): 41.2

Packaging Details

  • UPC: 07498343778
  • GTIN Package: 00074983437788
  • Standard Package Volume Ft3: 0.0528
  • Standard Package Weight Pounds: 3.2680
  • Std Package Height In: 3.4
  • Std Package Height MM: 86.36
  • Std Package Length In: 7.7
  • Std Package Length MM: 195.58
  • Std Package Width In: 3.45
  • Std Package Width MM: 87.63
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 10
  • Standard Carton Volume Ft3: 0.0528
  • Standard Carton Weight Pounds: 0.0000
  • Std Carton Length MM: 195.58
  • Std Ctn Qty: 0
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: MX
  • RoHS Compliant: Compliant
  • EAN: 00074983437788
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Lead Content Indicator: N
  • Restricted Use of Hazardous Substances: N
  • Hazardous Material Flag: N
  • Min Order Qty: 1
  • Pallet Quantity: 0
  • Pallet Volume: 0.000000
  • Pallet Weight: 0.0000

Overview

UPC 07498343778
Item Long Description The LCCX4/0-12-X Tin-Plated Copper Compression Lug, two-hole, long barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. The long barrel maximizes the number of crimps and provides premium wire pull-out strength and performance. The generously beveled wire entry prevents bent back strands when inserting the conductor into the barrel. UL Listed and CSA Certified.
GTiN 00074983437788
Size 4/0 AWG Class B, C, G, H, I, K, M and DLO
Color Purple
Type Tin-Plated Copper Compression Connectors - Lugs
Barrel Type Long Barrel Length With Inspection Window
Material Tin-Plated Copper
Stud Size 42767.00 IN
Number of Holes 2 Hole
Country of Origin MX
Angle Straight
Pkg Qty 10
Family Brand Name Panduit
Overall Length 5.73 in
Barrel Length 2.24 in
Color Coding Purple
Sub Brand Pan-Lug
CA Prop65 Warning No
Voltage 35,000 Volt
