PAN LCDX2-14A-E Panduit LCDX2-14A-E
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$1,332.22/c (100 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # LCDX2-14A-E
North Coast Part # 763009

Specifications

  • Product Segment: IEI
  • Inside Diameter (In.): 0.36
  • Outer Diameter (mm): 11.93
  • Inside Diameter (mm): 9.14
  • Outer Diameter (In.): 0.47
  • Product Type: Tin-Plated Copper Compression Connectors - Lugs
  • Lug Type: 2 Stud Hole Lug
  • Base Material: Copper
  • Class I Copper Flex Conductor Size (AWG): 2
  • DLO Copper Flex Conductor Size (AWG): 2
  • Class M Copper Flex Conductor Size (AWG): 2
  • Sub Brand: Pan-Lug™
  • Copper Code Conductor Size (AWG): 2
  • Class K Copper Flex Conductor Size (AWG): 2
  • Class G Copper Flex Conductor Size (AWG): 2
  • Class H Copper Flex Conductor Size (AWG): 2
  • Stud Hole Size (In.): 1/4
  • Stud Hole Size (mm): 6.4
  • Stud Hole Spacing (In.): 0.63
  • Stud Hole Spacing (mm): 16
  • Barrel Type: Standard Barrel with Inspection Window
  • Barrel Length (In.): 0.59
  • Barrel Length (mm): 15
  • Tongue Type: Standard
  • Tongue Width (In.): 0.7
  • Tongue Width (mm): 17.8
  • Tongue Angle: Straight
  • Tongue Thickness (mm): 2.8
  • Tongue Thickness (In.): 0.11
  • Overall Length (In.): 2.13
  • Overall Length (mm): 54.1
  • Finish/Coating: Tin-Plated
  • Standards Met: C22.2 No. 65-13, 486A-486B File #E52164
  • UL Temperature Rating (°C): 90
  • Maximum Voltage (kV): 35
  • Color Code: Brown
  • Panduit Die Index Number: P33
  • T & B Die Index Number: 10
  • Burndy Die Index Number: 10
  • Wire Strip Length (mm): 17.5
  • Wire Strip Length (In.): 11/16

Packaging Details

  • UPC: 07498342684
  • GTIN Package: 00074983426843
  • Standard Package Volume Ft3: 0.0328
  • Standard Package Weight Pounds: 1.0200
  • Std Package Height In: 3.4
  • Std Package Height MM: 86.36
  • Std Package Length In: 4.65
  • Std Package Length MM: 118.11
  • Std Package Width In: 3.4
  • Std Package Width MM: 86.36
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 20
  • Standard Carton Volume Ft3: 0.0328
  • Standard Carton Weight Pounds: 0.0000
  • Std Carton Length MM: 118.11
  • Std Ctn Qty: 0
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: MX
  • RoHS Compliant: Compliant
  • EAN: 00074983426843
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Lead Content Indicator: N
  • Restricted Use of Hazardous Substances: N
  • Hazardous Material Flag: N
  • Min Order Qty: 1
  • Pallet Quantity: 0
  • Pallet Volume: 0.000000
  • Pallet Weight: 0.0000

Overview

GTiN 00074983426843
Size #2 AWG Class B, C, G, H, I, K, M and DLO
Color Brown
Type Tin-Plated Copper Compression Connectors - Lugs
Barrel Type Standard Barrel Length With Inspection Window
Material Copper
Stud Size 42826.00 IN
Number of Holes 2 Hole
Country of Origin MX
Angle Straight
Pkg Qty 20
Family Brand Name Panduit
Overall Length 2.13 in
Barrel Length 0.59 in
Color Coding Brown
Sub Brand Pan-Lug
CA Prop65 Warning No
Product UPC 07498342684
Voltage 35,000 Volt
