PAN P18-P47-C Pin,Non-Ins,22-18AWG,

Specifications

• Product Segment: IEI
• UNSPSC: 39121409
• Pin Length (mm): 12.4
• Pin Length (In.): 0.49
• Insulation Material: Non-Insulated
• Maximum Wire Size (AWG): 22 - 18 AWG
• Wire Strip Length (In.): 0.30
• Wire Strip Length (mm): 7.1
• Standards Met: UL
• Maximum Voltage (kV): 2
• Maximum Voltage (V): 2000
• Base Material: Copper
• Finish/Coating: Tin-Plated
• Color Code: Metallic
• Barrel Type: Brazed
• Barrel Length (In.): 0.26
• Barrel Length (mm): 6.6
• Flammability Rating: NA
• Overall Length (mm): 19.1
• Sub Brand: Pan-Term
• Overall Length (In.): 0.75
• Packaging Type: Bottle
• Product Type: Loose Piece terminal

Packaging Details

• UPC: 07498381227
• GTIN Package: 00074983812271
• Standard Package Volume Ft3: 0.0074
• Standard Package Weight Pounds: 0.1700
• Std Package Height In: 1.75
• Std Package Height MM: 44.45
• Std Package Length In: 3.6
• Std Package Length MM: 91.44
• Std Package Width In: 1.8
• Std Package Width MM: 45.72
• Std. Pkg. UOM: Piece
• UOM EA PK: PK
• Std. Pkg. Qty.: 100
• GTIN Carton: 50074983812276
• Standard Carton Volume Ft3: 0.0074
• Standard Carton Weight Pounds: 1.7000
• Std Carton Height In: 3.65
• Std Carton Height MM: 92.71
• Std Carton Length In: 9.45
• Std Carton Length MM: 91.44
• Std Carton Width In: 3.95
• Std Carton Width MM: 100.33
• Std Ctn Qty: 1000
• Min. Order UOM: Piece
• Country of Origin 2Digit: MX
• RoHS Compliant: Compliant
• EAN: 00074983812271
• REACH Status: False
• Buy American Compliant: Y
• ARRA Compliant: Y
• Mercury Content Indicator: No
• Hazardous Material Flag: N
• Min Order Qty: 100
