PAN PBMS-H25-C14 CableMount,PushBut
Product image thumbnail 0
Product image thumbnail 1
$41.65/c (100 ea)
Usually ships within 6 to 10 Days
ea
Adding...
Order in multiples of 100 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # PBMS-H25-C14
North Coast Part # 601384

Specifications

  • UNSPSC: 39121717
  • Product Segment: IEI
  • Application: Push Button Mounts for Use where Both Sides of the Panel are Accessible
  • Product Type: Cable Tie Mount
  • Color: Gray
  • Flammability Rating: UL94V-2
  • Environment: Indoor
  • Material: Nylon 6.6
  • Maximum Compatible Panel Thickness (In.): 0.13
  • Maximum Compatible Panel Thickness (mm): 3.3
  • Mount Method: Push Barb
  • Overall Length (mm): 10.7
  • Overall Length (In.): 0.42
  • Overall Width (In.): 0.16
  • Overall Width (mm): 4.1
  • Standards Met: CE Compliant, UL Recognized: E136577, RoHS Compliant
  • Sub Brand: NA

Packaging Details

  • UPC: 07498358366
  • GTIN Package: 00074983583669
  • Standard Package Volume Ft3: 0.0185
  • Standard Package Weight Pounds: 0.1100
  • Std Package Height In: .7
  • Std Package Height MM: 17.78
  • Std Package Length In: 5.85
  • Std Package Length MM: 148.59
  • Std Package Width In: 4.9
  • Std Package Width MM: 124.46
  • Std. Pkg. UOM: Piece
  • UOM EA PK: PK
  • Std. Pkg. Qty.: 100
  • GTIN Carton: 50074983583664
  • Standard Carton Volume Ft3: 0.0185
  • Standard Carton Weight Pounds: 1.1000
  • Std Carton Height In: 4.4
  • Std Carton Height MM: 111.76
  • Std Carton Length In: 10.05
  • Std Carton Length MM: 148.59
  • Std Carton Width In: 6.3
  • Std Carton Width MM: 160.02
  • Std Ctn Qty: 1000
  • Min. Order UOM: Piece
  • Country of Origin 2Digit: US
  • RoHS Compliant: Compliant
  • EAN: 00074983583669
  • REACH Status: False
  • California Pro65 Cancer: No
  • Buy American Compliant: Y
  • ARRA Compliant: Y
  • Mercury Content Indicator: No
  • Hazardous Material Flag: N
  • Min Order Qty: 1,000

Overview

UPC 07498358366
Item Long Description The push button cable tie mount requires a 0.25" (6.4 mm) hole and is gray. It is made of nylon 6.6, which increases mechanical strength, heat and wear resistance, and stiffness. It comes in packages of 100.
GTiN 00074983583669
Width 0.16 in
Color Gray
Operating Temperature -40F (-40C) - 185F (85C)
Type Cable Tie Mount
Material Nylon
Applications Indoor
Country of Origin US
Pkg Qty 100
Family Brand Name Panduit
Overall Length 0.42 in
CA Prop65 Warning No
UNSPSC 39121717
Mounting Type Push Barb
